Panasonic, ETQP4M Shielded Wire-wound SMD Inductor with a Metal Composite Core, 22 μH ±20% 3.9A Idc
- RS Stock No.:
- 238-3601
- Mfr. Part No.:
- ETQP4M220KFM
- Brand:
- Panasonic
500 In stock - FREE next working day delivery available
Added
Price Each (On a Reel of 500)
£0.402
(exc. VAT)
£0.482
(inc. VAT)
| Units | Per unit | Per Reel* |
| 500 + | £0.402 | £201.00 |
| *price indicative | ||
- RS Stock No.:
- 238-3601
- Mfr. Part No.:
- ETQP4M220KFM
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
Product Details
The Panasonic Power Inductor has high heat resistance and high reliability using metal composite core. It has high vibration resistance as result of newly developed integral construction. The excellent inductance stability using ferrous alloy magnetic material. It has shielded construction.
Operation up to 150°C including self heat
High bias current
Temperature stability
Low audible noise
Noise filter for various drive circuitry requiring high temperature operation and peak current handling capability
High bias current
Temperature stability
Low audible noise
Noise filter for various drive circuitry requiring high temperature operation and peak current handling capability
Specifications
Attribute | Value |
|---|---|
| Inductance | 22 μH |
| Maximum DC Current | 3.9A |
| Length | 7.4mm |
| Automotive Standard | AEC-Q200 |
| Depth | 7mm |
| Shielded | Yes |
| Tolerance | ±20% |
| Series | ETQP4M |
| Core Material | Metal Composite |
