Vishay, IHLP, 2225 Shielded Surface Mount Inductor with a Metal Composite Core, 330 nH ±20 % 20 A Idc
- RS Stock No.:
- 223-7284
- Mfr. Part No.:
- IHLP2525CZERR33M01
- Brand:
- Vishay
Bulk discount available
Subtotal (1 tape of 5 units)*
£3.18
(exc. VAT)
£3.815
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- Final 265 unit(s), ready to ship
Units | Per unit | Per Tape* |
|---|---|---|
| 5 - 45 | £0.636 | £3.18 |
| 50 - 120 | £0.452 | £2.26 |
| 125 - 245 | £0.38 | £1.90 |
| 250 - 495 | £0.324 | £1.62 |
| 500 + | £0.302 | £1.51 |
*price indicative
- RS Stock No.:
- 223-7284
- Mfr. Part No.:
- IHLP2525CZERR33M01
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Surface Mount Inductor | |
| Inductance | 330 nH | |
| Maximum DC Current | 20A | |
| Package/Case | 2225 | |
| Length | 6.7mm | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 3.9mΩ | |
| Series | IHLP | |
| Inductance Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | JEDEC, RoHS | |
| Core Material | Metal Composite | |
| Termination Style | Surface Mount | |
| Depth | 6.47mm | |
| Height | 3mm | |
| Moulded | Yes | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Surface Mount Inductor | ||
Inductance 330 nH | ||
Maximum DC Current 20A | ||
Package/Case 2225 | ||
Length 6.7mm | ||
Automotive Standard No | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 3.9mΩ | ||
Series IHLP | ||
Inductance Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals JEDEC, RoHS | ||
Core Material Metal Composite | ||
Termination Style Surface Mount | ||
Depth 6.47mm | ||
Height 3mm | ||
Moulded Yes | ||
Inductor Construction Shielded | ||
The Vishay IHLP commercial inductors, high saturation series It handles high transient current spikes without saturation. It has ultra low buzz noise, due to composite construction. It has 330 nH inductance.
RoHS compliant
Halogen free
