Vishay, IHLP, 2225 Shielded Surface Mount Inductor with a Metal Composite Core, 3.3 μH ±20 % 9.2 A Idc
- RS Stock No.:
- 223-7292
- Distrelec Article No.:
- 304-39-792
- Mfr. Part No.:
- IHLP3232DZER3R3M01
- Brand:
- Vishay
Bulk discount available
View bulk pricing optionsSubtotal (1 tape of 5 units)*
£4.45
(exc. VAT)
£5.35
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 350 unit(s) shipping from 01 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 5 - 45 | £0.89 | £4.45 |
| 50 - 120 | £0.632 | £3.16 |
| 125 - 245 | £0.578 | £2.89 |
| 250 - 495 | £0.534 | £2.67 |
| 500 + | £0.49 | £2.45 |
*price indicative
- RS Stock No.:
- 223-7292
- Distrelec Article No.:
- 304-39-792
- Mfr. Part No.:
- IHLP3232DZER3R3M01
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Surface Mount Inductor | |
| Inductance | 3.3μH | |
| Maximum DC Current | 9.2A | |
| Package/Case | 2225 | |
| Length | 8mm | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 17.7mΩ | |
| Maximum Operating Temperature | 125°C | |
| Inductance Tolerance | ±20 % | |
| Series | IHLP | |
| Termination Style | Surface Mount | |
| Standards/Approvals | RoHS, JEDEC | |
| Depth | 4mm | |
| Height | 4mm | |
| Core Material | Metal Composite | |
| Maximum Self Resonant Frequency | 25MHz | |
| Moulded | Yes | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Surface Mount Inductor | ||
Inductance 3.3μH | ||
Maximum DC Current 9.2A | ||
Package/Case 2225 | ||
Length 8mm | ||
Automotive Standard No | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 17.7mΩ | ||
Maximum Operating Temperature 125°C | ||
Inductance Tolerance ±20 % | ||
Series IHLP | ||
Termination Style Surface Mount | ||
Standards/Approvals RoHS, JEDEC | ||
Depth 4mm | ||
Height 4mm | ||
Core Material Metal Composite | ||
Maximum Self Resonant Frequency 25MHz | ||
Moulded Yes | ||
Inductor Construction Shielded | ||
The Vishay IHLP commercial inductors it handles high transient current spikes without saturation. It has ultra low buzz noise, due to composite construction. It has 3.3 μH inductance.
RoHS compliant
Halogen free
