Bourns, SRP6540 Shielded Multilayer Surface Mount Inductor with a Carbonyl Powder Core, 1 μH ±20 % 4 A Idc
- RS Stock No.:
- 223-1837
- Mfr. Part No.:
- SRP6540-100M
- Brand:
- Bourns
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 223-1837
- Mfr. Part No.:
- SRP6540-100M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Multilayer Surface Mount Inductor | |
| Inductance | 1μH | |
| Maximum DC Current | 4A | |
| Package/Case | Surface Mount | |
| Packaging | Reel | |
| Length | 7.2mm | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 78.5mΩ | |
| Inductance Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Series | SRP6540 | |
| Diameter | 330mm | |
| Depth | 4mm | |
| Termination Style | Solder | |
| Height | 4mm | |
| Core Material | Carbonyl Powder | |
| Standards/Approvals | RoHS | |
| Inductor Construction | Shielded | |
| Moulded | Yes | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Multilayer Surface Mount Inductor | ||
Inductance 1μH | ||
Maximum DC Current 4A | ||
Package/Case Surface Mount | ||
Packaging Reel | ||
Length 7.2mm | ||
Automotive Standard No | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 78.5mΩ | ||
Inductance Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Series SRP6540 | ||
Diameter 330mm | ||
Depth 4mm | ||
Termination Style Solder | ||
Height 4mm | ||
Core Material Carbonyl Powder | ||
Standards/Approvals RoHS | ||
Inductor Construction Shielded | ||
Moulded Yes | ||
- COO (Country of Origin):
- TW
The Bourns Electronics Multilayer Surface Mount Inductor
come with a core material of Carbonyl Powder works with maximum DC current of 4 A and maximum DC resistance of 78.5 mOhms.
20% tolerance
-55°C to +105°C operating temperature
