Bourns, SRP4020TA Shielded Multilayer Surface Mount Inductor with a Carbonyl Powder Core, 4.7 μH 20 % 2.6 A Idc Q:10
- RS Stock No.:
- 223-1833
- Mfr. Part No.:
- SRP4020TA-4R7M
- Brand:
- Bourns
Subtotal (1 reel of 3000 units)*
£1,179.00
(exc. VAT)
£1,416.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 24 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 + | £0.393 | £1,179.00 |
*price indicative
- RS Stock No.:
- 223-1833
- Mfr. Part No.:
- SRP4020TA-4R7M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Inductance | 4.7 μH | |
| Product Type | Multilayer Surface Mount Inductor | |
| Maximum DC Current | 2.6A | |
| Package/Case | Surface Mount | |
| Length | 4.45mm | |
| Packaging | Reel | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Maximum DC Resistance | 95mΩ | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 150°C | |
| Series | SRP4020TA | |
| Inductance Tolerance | 20 % | |
| Termination Style | Solder | |
| Depth | 1.8mm | |
| Standards/Approvals | RoHS | |
| Core Material | Carbonyl Powder | |
| Maximum Self Resonant Frequency | 27MHz | |
| Minimum Quality Factor | 10 | |
| Moulded | Yes | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Inductance 4.7 μH | ||
Product Type Multilayer Surface Mount Inductor | ||
Maximum DC Current 2.6A | ||
Package/Case Surface Mount | ||
Length 4.45mm | ||
Packaging Reel | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Maximum DC Resistance 95mΩ | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 150°C | ||
Series SRP4020TA | ||
Inductance Tolerance 20 % | ||
Termination Style Solder | ||
Depth 1.8mm | ||
Standards/Approvals RoHS | ||
Core Material Carbonyl Powder | ||
Maximum Self Resonant Frequency 27MHz | ||
Minimum Quality Factor 10 | ||
Moulded Yes | ||
Inductor Construction Shielded | ||
- COO (Country of Origin):
- TW
The Bourns Electronics Multilayer Surface Mount Inductor
come with a core material of Carbonyl Powder works with maximum DC current of 2.6 A and maximum DC resistance of 105 mOhms.
20% tolerance
-55°C to +105°C operating temperature
