Bourns, SRP1265A Shielded Multilayer Surface Mount Inductor with a Carbonyl Powder Core, 1 μH 20 % 48 A Idc Q:20
- RS Stock No.:
- 223-1828
- Mfr. Part No.:
- SRP1265A-1R0M
- Brand:
- Bourns
Bulk discount available
Subtotal (1 tape of 5 units)*
£6.18
(exc. VAT)
£7.415
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 610 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 5 - 20 | £1.236 | £6.18 |
| 25 - 45 | £1.06 | £5.30 |
| 50 - 95 | £0.936 | £4.68 |
| 100 - 195 | £0.918 | £4.59 |
| 200 + | £0.856 | £4.28 |
*price indicative
- RS Stock No.:
- 223-1828
- Mfr. Part No.:
- SRP1265A-1R0M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Inductance | 1 μH | |
| Product Type | Multilayer Surface Mount Inductor | |
| Maximum DC Current | 48A | |
| Package/Case | Surface Mount | |
| Length | 12.5mm | |
| Packaging | 500 pieces per 13 in Reel | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 2mΩ | |
| Series | SRP1265A | |
| Inductance Tolerance | 20 % | |
| Maximum Operating Temperature | 150°C | |
| Core Material | Carbonyl Powder | |
| Depth | 6.2mm | |
| Standards/Approvals | RoHS | |
| Maximum Self Resonant Frequency | 45MHz | |
| Minimum Quality Factor | 20 | |
| Inductor Construction | Shielded | |
| Moulded | Yes | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Inductance 1 μH | ||
Product Type Multilayer Surface Mount Inductor | ||
Maximum DC Current 48A | ||
Package/Case Surface Mount | ||
Length 12.5mm | ||
Packaging 500 pieces per 13 in Reel | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 2mΩ | ||
Series SRP1265A | ||
Inductance Tolerance 20 % | ||
Maximum Operating Temperature 150°C | ||
Core Material Carbonyl Powder | ||
Depth 6.2mm | ||
Standards/Approvals RoHS | ||
Maximum Self Resonant Frequency 45MHz | ||
Minimum Quality Factor 20 | ||
Inductor Construction Shielded | ||
Moulded Yes | ||
- COO (Country of Origin):
- CN
The Bourns Electronics Multilayer Surface Mount Inductor
come with a core material of Carbonyl Powder works with maximum DC current of 48 A and maximum DC resistance of 2.3 mOhms.
20% tolerance
-55°C to +105°C operating temperature
