Wurth, WE-PD, 1210 Shielded Wire-wound SMD Inductor with a Ferrite Core, 2.2 mH ±20% Shielded 530mA Idc
- RS Stock No.:
- 185-7429
- Distrelec Article No.:
- 301-35-774
- Mfr. Part No.:
- 7447709222
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 unit)*
£2.14
(exc. VAT)
£2.57
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 29 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £2.14 |
5 - 24 | £2.09 |
25 - 99 | £1.87 |
100 + | £1.66 |
*price indicative
- RS Stock No.:
- 185-7429
- Distrelec Article No.:
- 301-35-774
- Mfr. Part No.:
- 7447709222
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Inductance | 2.2 mH | |
Maximum DC Current | 530mA | |
Package/Case | 1210 | |
Length | 12mm | |
Depth | 12mm | |
Automotive Standard | AEC-Q200 | |
Height | 10mm | |
Dimensions | 12 x 12 x 10mm | |
Shielded | Yes | |
Tolerance | ±20% | |
Maximum DC Resistance | 3.75Ω | |
Series | WE-PD | |
Core Material | Ferrite | |
Maximum Self Resonant Frequency | 0.66MHz | |
Inductor Construction | Shielded | |
Maximum Operating Temperature | +125°C | |
Minimum Operating Temperature | -40°C | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Inductance 2.2 mH | ||
Maximum DC Current 530mA | ||
Package/Case 1210 | ||
Length 12mm | ||
Depth 12mm | ||
Automotive Standard AEC-Q200 | ||
Height 10mm | ||
Dimensions 12 x 12 x 10mm | ||
Shielded Yes | ||
Tolerance ±20% | ||
Maximum DC Resistance 3.75Ω | ||
Series WE-PD | ||
Core Material Ferrite | ||
Maximum Self Resonant Frequency 0.66MHz | ||
Inductor Construction Shielded | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -40°C | ||
Ultra low RDC and RAC
Highest possible saturation current based on Ferrite
Suitable for switching frequency up to 10MHz
Temperature dependent parameter available on Redexpert
Operating Temperature from -40°C to +125°C / +150°C
Types- WE-PD: Since always with low loss material, tight tolerances and high saturation behavior compared to other manufacturers in the market, WE-PD Robust: Plastic base improves the mechanical stability and efficiency, WE-PD Performance: MnZn core improves Saturation and RDC for highest efficiency
Applications
Switch Mode Power supplies from 0,1W up to 300W
Integrated DC DC Converter
Ideal for Switch Mode Power supplies with extreme high efficiency (>95%)
Highest possible saturation current based on Ferrite
Suitable for switching frequency up to 10MHz
Temperature dependent parameter available on Redexpert
Operating Temperature from -40°C to +125°C / +150°C
Types- WE-PD: Since always with low loss material, tight tolerances and high saturation behavior compared to other manufacturers in the market, WE-PD Robust: Plastic base improves the mechanical stability and efficiency, WE-PD Performance: MnZn core improves Saturation and RDC for highest efficiency
Applications
Switch Mode Power supplies from 0,1W up to 300W
Integrated DC DC Converter
Ideal for Switch Mode Power supplies with extreme high efficiency (>95%)
