TDK, VLS-EX, 5045 Shielded Wire-wound SMD Inductor with a Ferrite Core, 220 μH ±20% Wire-Wound 450mA Idc
- RS Stock No.:
- 181-5295
- Mfr. Part No.:
- VLS5045EX-221M
- Brand:
- TDK
2000 In stock - FREE next working day delivery available
Price Each (On a Reel of 250)
£0.154
(exc. VAT)
£0.185
(inc. VAT)
Units | Per unit | Per Reel* |
---|---|---|
250 - 750 | £0.154 | £38.50 |
1000 + | £0.125 | £31.25 |
*price indicative
- RS Stock No.:
- 181-5295
- Mfr. Part No.:
- VLS5045EX-221M
- Brand:
- TDK
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Magnetic shield type wound inductor for power circuits.
High magnetic shield construction achieved by a ferrite magnetic material and compatible with high-density mounting.
Larger current and lower Rdc were achieved by optimizing the ferrite core figure.
APPLICATION
TV, STB, gaming equipment, other AV equipment
High magnetic shield construction achieved by a ferrite magnetic material and compatible with high-density mounting.
Larger current and lower Rdc were achieved by optimizing the ferrite core figure.
APPLICATION
TV, STB, gaming equipment, other AV equipment
Specifications
Attribute | Value |
---|---|
Inductance | 220 μH |
Maximum DC Current | 450mA |
Package/Case | 5045 |
Length | 5mm |
Depth | 5mm |
Height | 4.5mm |
Dimensions | 5 x 5 x 4.5mm |
Shielded | Yes |
Tolerance | ±20% |
Maximum DC Resistance | 1.365Ω |
Series | VLS-EX |
Core Material | Ferrite |
Minimum Operating Temperature | -40°C |
Maximum Operating Temperature | +105°C |
Inductor Construction | Wire-Wound |
