TDK, VLS-EX-H, 5045 Shielded Wirewound Surface Mount Inductor with a Ferrite Core, 150 μH ±20 % 560 mA Idc

View all Surface Mount Inductors

Subtotal (1 reel of 1500 units)*

£193.50

(exc. VAT)

£232.50

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 25 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Reel*
1500 +£0.129£193.50

*price indicative

RS Stock No.:
211-9535
Mfr. Part No.:
VLS5045EX-151M
Brand:
TDK
Find similar products by selecting one or more attributes.
Select all

Brand

TDK

Product Type

Wirewound Surface Mount Inductor

Inductance

150μH

Maximum DC Current

560mA

Package/Case

5045

Packaging

Tape & Reel

Length

5mm

Automotive Standard

AEC-Q200

Shielding

Yes

Maximum DC Resistance

949mΩ

Minimum Operating Temperature

-40°C

Series

VLS-EX-H

Maximum Operating Temperature

125°C

Inductance Tolerance

±20 %

Depth

5.3mm

Standards/Approvals

RoHS

Core Material

Ferrite

Termination Style

Surface Mount

Height

4.5mm

Inductor Construction

Shielded

COO (Country of Origin):
KR
The TDK VLS-EX-H series magnetic shield wire wound ferrite core surface mount inductor has inductance rating 150μH ±20% at 100kHz. It is used for automotive-related equipment like ECM, airbags, headlights, electronic power steering, meters, ABS, etc.

Magnetic shield type wound inductor for power circuits

High magnetic shield construction achieved by a ferrite magnetic material and compatible with high-density mounting

Larger current and lower Rdc were achieved by optimizing the ferrite core figure
