Bourns, SRN3015, 3015 Shielded Wirewound Surface Mount Inductor with a Ferrite Core, 100 μH Semi Shielded ±20 % 290 mA
- RS Stock No.:
- 180-9001
- Distrelec Article No.:
- 304-30-159
- Mfr. Part No.:
- SRN3015-101M
- Brand:
- Bourns
Subtotal (1 reel of 100 units)*
£18.80
(exc. VAT)
£22.60
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 1,800 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 100 + | £0.188 | £18.80 |
*price indicative
- RS Stock No.:
- 180-9001
- Distrelec Article No.:
- 304-30-159
- Mfr. Part No.:
- SRN3015-101M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Wirewound Surface Mount Inductor | |
| Inductance | 100μH | |
| Maximum DC Current | 290mA | |
| Package/Case | 3015 | |
| Length | 3mm | |
| Packaging | Tape & Reel | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Maximum DC Resistance | 2.92Ω | |
| Minimum Operating Temperature | -40°C | |
| Series | SRN3015 | |
| Inductance Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Depth | 3mm | |
| Termination Style | Solder | |
| Standards/Approvals | RoHS | |
| Core Material | Ferrite | |
| Height | 1.5mm | |
| Maximum Self Resonant Frequency | 11MHz | |
| Minimum Quality Factor | 27 | |
| Inductor Construction | Semi Shielded | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Wirewound Surface Mount Inductor | ||
Inductance 100μH | ||
Maximum DC Current 290mA | ||
Package/Case 3015 | ||
Length 3mm | ||
Packaging Tape & Reel | ||
Automotive Standard No | ||
Shielding Yes | ||
Maximum DC Resistance 2.92Ω | ||
Minimum Operating Temperature -40°C | ||
Series SRN3015 | ||
Inductance Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Depth 3mm | ||
Termination Style Solder | ||
Standards/Approvals RoHS | ||
Core Material Ferrite | ||
Height 1.5mm | ||
Maximum Self Resonant Frequency 11MHz | ||
Minimum Quality Factor 27 | ||
Inductor Construction Semi Shielded | ||
Semi-shielded construction
Miniature size
Component height 1.5 mm
Inductance range: 1 to 100 μH
Rated current up to 2.35 A
Halogen free
Applications
DC/DC converters
Notebook computers
Digital video cameras
HDDs
Cell phones
Televisions, LCD displays
