Vishay, IHLP, EK Shielded Surface Mount Inductor with a Metal Composite Core, 22 μH ±20 % 2.9 A Idc
- RS Stock No.:
- 565-016
- Mfr. Part No.:
- IHLP2525CZEK220M1A
- Brand:
- Vishay
Subtotal (1 reel of 2500 units)*
£1,255.00
(exc. VAT)
£1,505.00
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Reel* |
|---|---|---|
| 2500 + | £0.502 | £1,255.00 |
*price indicative
- RS Stock No.:
- 565-016
- Mfr. Part No.:
- IHLP2525CZEK220M1A
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Inductance | 22μH | |
| Product Type | Surface Mount Inductor | |
| Maximum DC Current | 2.9A | |
| Package/Case | EK | |
| Length | 0.27in | |
| Packaging | Tape & Reel | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Pin Count | 2 | |
| Maximum DC Resistance | 135mΩ | |
| Inductance Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Series | IHLP | |
| Standards/Approvals | RoHS | |
| Core Material | Metal Composite | |
| Diameter | 0.12in | |
| Height | 3mm | |
| Depth | 0.12in | |
| Termination Style | EK | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Inductance 22μH | ||
Product Type Surface Mount Inductor | ||
Maximum DC Current 2.9A | ||
Package/Case EK | ||
Length 0.27in | ||
Packaging Tape & Reel | ||
Automotive Standard No | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Pin Count 2 | ||
Maximum DC Resistance 135mΩ | ||
Inductance Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Series IHLP | ||
Standards/Approvals RoHS | ||
Core Material Metal Composite | ||
Diameter 0.12in | ||
Height 3mm | ||
Depth 0.12in | ||
Termination Style EK | ||
Inductor Construction Shielded | ||
The Vishay Automotive inductors with shielded construction support frequency ranges up to 1.0 MHz, ensuring stable performance in power management systems. They offer the lowest DCR per μH in their package size for efficient operation. The powdered iron core provides soft saturation characteristics, enhancing durability under varying load conditions. Ideal for automotive DC/DC converter applications.
Handles high transient current spikes without hard saturation
Ultra low buzz noise due to composite construction
AEC Q200 qualified
RoHS Compliant
Halogen free
