Bourns, SRP5030TA, 5030 Shielded Power Inductor with a Carbonyl Powder Core, 4.7 μH ±20 % 4.6 A Idc Q:15
- RS Stock No.:
- 466-272
- Mfr. Part No.:
- SRP5030TA-4R7M
- Brand:
- Bourns
Bulk discount available
View bulk pricing optionsSubtotal (1 bag of 2 units)*
£1.78
(exc. VAT)
£2.14
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 1,518 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 2 - 18 | £0.89 | £1.78 |
| 20 - 48 | £0.745 | £1.49 |
| 50 - 198 | £0.47 | £0.94 |
| 200 - 998 | £0.46 | £0.92 |
| 1000 + | £0.45 | £0.90 |
*price indicative
- RS Stock No.:
- 466-272
- Mfr. Part No.:
- SRP5030TA-4R7M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Power Inductor | |
| Inductance | 4.7μH | |
| Maximum DC Current | 4.6A | |
| Package/Case | 5030 | |
| Packaging | 2000 pieces per 13 in Reel | |
| Length | 5.7mm | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Maximum DC Resistance | 128mΩ | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 150°C | |
| Series | SRP5030TA | |
| Inductance Tolerance | ±20 % | |
| Standards/Approvals | RoHS | |
| Core Material | Carbonyl Powder | |
| Diameter | 5.2mm | |
| Height | 5.2mm | |
| Depth | 5.2mm | |
| Maximum Self Resonant Frequency | 320MHz | |
| Inductor Construction | Shielded | |
| Minimum Quality Factor | 15 | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Power Inductor | ||
Inductance 4.7μH | ||
Maximum DC Current 4.6A | ||
Package/Case 5030 | ||
Packaging 2000 pieces per 13 in Reel | ||
Length 5.7mm | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Maximum DC Resistance 128mΩ | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 150°C | ||
Series SRP5030TA | ||
Inductance Tolerance ±20 % | ||
Standards/Approvals RoHS | ||
Core Material Carbonyl Powder | ||
Diameter 5.2mm | ||
Height 5.2mm | ||
Depth 5.2mm | ||
Maximum Self Resonant Frequency 320MHz | ||
Inductor Construction Shielded | ||
Minimum Quality Factor 15 | ||
- COO (Country of Origin):
- CN
The Bourns Shielded power inductors feature a shielded construction for reduced interference, with a carbonyl powder core for high saturation current handling. Ideal for power applications that require efficient energy transfer and minimal electromagnetic noise.
RoHS compliant
AEC Q200 compliant
