Bourns, SRP4020FA, 4020 Shielded Power Inductor with a Metal Alloy Powder Core, 2.2 μH ±20 % 8 A Idc Q:15
- RS Stock No.:
- 466-262
- Mfr. Part No.:
- SRP4020FA-2R2M
- Brand:
- Bourns
Bulk discount available
Subtotal (1 bag of 2 units)*
£1.63
(exc. VAT)
£1.956
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2,710 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 2 - 18 | £0.815 | £1.63 |
| 20 - 48 | £0.685 | £1.37 |
| 50 - 198 | £0.425 | £0.85 |
| 200 - 998 | £0.415 | £0.83 |
| 1000 + | £0.405 | £0.81 |
*price indicative
- RS Stock No.:
- 466-262
- Mfr. Part No.:
- SRP4020FA-2R2M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Inductance | 2.2 μH | |
| Product Type | Power Inductor | |
| Maximum DC Current | 8A | |
| Package/Case | 4020 | |
| Packaging | 3000 pieces per 13 in Reel | |
| Length | 4.1mm | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 57.2mΩ | |
| Series | SRP4020FA | |
| Maximum Operating Temperature | 155°C | |
| Inductance Tolerance | ±20 % | |
| Core Material | Metal Alloy Powder | |
| Height | 4.1mm | |
| Diameter | 4.1 mm | |
| Depth | 4.1mm | |
| Standards/Approvals | RoHS Compliant | |
| Maximum Self Resonant Frequency | 90MHz | |
| Minimum Quality Factor | 15 | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Inductance 2.2 μH | ||
Product Type Power Inductor | ||
Maximum DC Current 8A | ||
Package/Case 4020 | ||
Packaging 3000 pieces per 13 in Reel | ||
Length 4.1mm | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 57.2mΩ | ||
Series SRP4020FA | ||
Maximum Operating Temperature 155°C | ||
Inductance Tolerance ±20 % | ||
Core Material Metal Alloy Powder | ||
Height 4.1mm | ||
Diameter 4.1 mm | ||
Depth 4.1mm | ||
Standards/Approvals RoHS Compliant | ||
Maximum Self Resonant Frequency 90MHz | ||
Minimum Quality Factor 15 | ||
Inductor Construction Shielded | ||
- COO (Country of Origin):
- CN
The Bourns Shielded power inductors feature a shielded construction to reduce electromagnetic interference. They use a metal alloy powder core for high saturation current handling and flat wire design for improved efficiency. These inductors are ideal for applications that require compact, high performance power management with minimal noise.
RoHS compliant
AEC Q200 compliant
