Bourns, SRU1048, 1048 Shielded Power Inductor with a Ferrite Core, 100 μH ±30 % 1.2 A Idc Q:26
- RS Stock No.:
- 466-178
- Mfr. Part No.:
- SRU1048-101Y
- Brand:
- Bourns
Bulk discount available
Subtotal (1 bag of 2 units)*
£1.34
(exc. VAT)
£1.60
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 1,100 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 2 - 18 | £0.67 | £1.34 |
| 20 - 48 | £0.56 | £1.12 |
| 50 - 198 | £0.35 | £0.70 |
| 200 - 998 | £0.345 | £0.69 |
| 1000 + | £0.335 | £0.67 |
*price indicative
- RS Stock No.:
- 466-178
- Mfr. Part No.:
- SRU1048-101Y
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Power Inductor | |
| Inductance | 100μH | |
| Maximum DC Current | 1.2A | |
| Package/Case | 1048 | |
| Length | 10mm | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Minimum Operating Temperature | -40°C | |
| Maximum DC Resistance | 160.0mΩ | |
| Series | SRU1048 | |
| Maximum Operating Temperature | 125°C | |
| Inductance Tolerance | ±30 % | |
| Standards/Approvals | RoHS | |
| Diameter | 10mm | |
| Height | 10mm | |
| Core Material | Ferrite | |
| Depth | 10mm | |
| Maximum Self Resonant Frequency | 7.96MHz | |
| Inductor Construction | Shielded | |
| Minimum Quality Factor | 26 | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Power Inductor | ||
Inductance 100μH | ||
Maximum DC Current 1.2A | ||
Package/Case 1048 | ||
Length 10mm | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Minimum Operating Temperature -40°C | ||
Maximum DC Resistance 160.0mΩ | ||
Series SRU1048 | ||
Maximum Operating Temperature 125°C | ||
Inductance Tolerance ±30 % | ||
Standards/Approvals RoHS | ||
Diameter 10mm | ||
Height 10mm | ||
Core Material Ferrite | ||
Depth 10mm | ||
Maximum Self Resonant Frequency 7.96MHz | ||
Inductor Construction Shielded | ||
Minimum Quality Factor 26 | ||
The Bourns Shielded SMD power inductors, available in the E6 series, feature a unit height of 4.8 mm for space-efficient designs. They are ideal for high performance applications that require reliable power management in compact spaces.
RoHS compliant
