Bourns, SRP1265A, 1265 Shielded Power Inductor with a Carbonyl Powder Core, 1.5 μH 20 % 27 A Idc Q:30
- RS Stock No.:
- 466-127
- Mfr. Part No.:
- SRP1265A-1R5M
- Brand:
- Bourns
Bulk discount available
View bulk pricing optionsSubtotal (1 bag of 2 units)*
£1.71
(exc. VAT)
£2.052
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 448 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 2 - 18 | £0.855 | £1.71 |
| 20 - 48 | £0.715 | £1.43 |
| 50 - 198 | £0.495 | £0.99 |
| 200 - 998 | £0.49 | £0.98 |
| 1000 + | £0.48 | £0.96 |
*price indicative
- RS Stock No.:
- 466-127
- Mfr. Part No.:
- SRP1265A-1R5M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Power Inductor | |
| Inductance | 1.5μH | |
| Maximum DC Current | 27A | |
| Package/Case | 1265 | |
| Packaging | 500 pieces per 13 in Reel | |
| Length | 13.5mm | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 90mΩ | |
| Maximum Operating Temperature | 150°C | |
| Series | SRP1265A | |
| Inductance Tolerance | 20 % | |
| Core Material | Carbonyl Powder | |
| Diameter | 12.5mm | |
| Depth | 12.5mm | |
| Standards/Approvals | AEC-Q200, RoHS | |
| Height | 12.5mm | |
| Maximum Self Resonant Frequency | 55MHz | |
| Minimum Quality Factor | 30 | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Power Inductor | ||
Inductance 1.5μH | ||
Maximum DC Current 27A | ||
Package/Case 1265 | ||
Packaging 500 pieces per 13 in Reel | ||
Length 13.5mm | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 90mΩ | ||
Maximum Operating Temperature 150°C | ||
Series SRP1265A | ||
Inductance Tolerance 20 % | ||
Core Material Carbonyl Powder | ||
Diameter 12.5mm | ||
Depth 12.5mm | ||
Standards/Approvals AEC-Q200, RoHS | ||
Height 12.5mm | ||
Maximum Self Resonant Frequency 55MHz | ||
Minimum Quality Factor 30 | ||
Inductor Construction Shielded | ||
- COO (Country of Origin):
- CN
The Bourns Shielded power inductors feature a shielded construction to minimize interference, with a carbonyl powder core for enhanced performance and high saturation current handling.
RoHS compliant
AEC Q200 compliant
