Bourns, SRP1050WA, 1050 Shielded Power Inductor with a Metal Alloy Powder Core, 10 μH ±20% Shielded 9A Idc Q:20
- RS Stock No.:
- 466-119
- Mfr. Part No.:
- SRP1050WA-100M
- Brand:
- Bourns
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 466-119
- Mfr. Part No.:
- SRP1050WA-100M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Inductance | 10 μH | |
| Maximum DC Current | 9A | |
| Package/Case | 1050 | |
| Length | 11mm | |
| Depth | 10mm | |
| Automotive Standard | AEC-Q200 | |
| Shielded | Yes | |
| Tolerance | ±20% | |
| Series | SRP1050WA | |
| Core Material | Metal Alloy Powder | |
| Minimum Quality Factor | 20 | |
| Inductor Construction | Shielded | |
Select all | ||
|---|---|---|
Brand Bourns | ||
Inductance 10 μH | ||
Maximum DC Current 9A | ||
Package/Case 1050 | ||
Length 11mm | ||
Depth 10mm | ||
Automotive Standard AEC-Q200 | ||
Shielded Yes | ||
Tolerance ±20% | ||
Series SRP1050WA | ||
Core Material Metal Alloy Powder | ||
Minimum Quality Factor 20 | ||
Inductor Construction Shielded | ||
- COO (Country of Origin):
- CN
The Bourns Shielded power inductors feature a shielded construction to reduce radiation, ensuring minimal interference. The metal alloy powder core provides high saturation current handling, while the wide side terminal enhances mechanical strength. With high vibration resistance, they are suitable for rugged applications that require durability and reliable performance in harsh environments.
RoHS compliant
AEC Q200 compliant
AEC Q200 compliant
