Murata 1F Supercapacitor ±20% Tolerance, DMF 5.5V dc, Surface Mount
- RS Stock No.:
- 901-5326
- Mfr. Part No.:
- DMF4B5R5G105M3DTA0
- Brand:
- Murata
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 901-5326
- Mfr. Part No.:
- DMF4B5R5G105M3DTA0
- Brand:
- Murata
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Murata | |
| Capacitance | 1F | |
| Voltage | 5.5V dc | |
| Mounting Type | Surface Mount | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +70°C | |
| Dimensions | 14 x 30 x 3.7mm | |
| Lead Pitch | 1.8mm | |
| Leakage Current | <10 μA | |
| Equivalent Series Resistance | 40mΩ | |
| Lifetime | 1000h | |
| Series | DMF | |
| Tolerance | ±20% | |
| Tolerance Plus | +20% | |
| Depth | 14mm | |
| Capacitor Family | Electric Double Layer | |
| Terminal Type | Flat | |
| Tolerance Minus | -20% | |
Select all | ||
|---|---|---|
Brand Murata | ||
Capacitance 1F | ||
Voltage 5.5V dc | ||
Mounting Type Surface Mount | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +70°C | ||
Dimensions 14 x 30 x 3.7mm | ||
Lead Pitch 1.8mm | ||
Leakage Current <10 μA | ||
Equivalent Series Resistance 40mΩ | ||
Lifetime 1000h | ||
Series DMF | ||
Tolerance ±20% | ||
Tolerance Plus +20% | ||
Depth 14mm | ||
Capacitor Family Electric Double Layer | ||
Terminal Type Flat | ||
Tolerance Minus -20% | ||
Murata DMF Series EDLC Super Capacitor
DMF series EDLC super capacitor with a high power output and high energy of 5.5V, a wide operating temperature range of -30 to +70°C, low ESR of 40mΩ to 60mΩ, ESR change @ -30°C < twice the normal ESR and a low leakage current and a long life cycle exceeding 100k cycles. This DMF series EDLC super capacitor offers a range of benefits including levelling the high peak load up to hundreds of milli-seconds, quick charge and discharge of high energy and providing maintenance-free energy storage with flexible charge. Typical applications for this DMF EDLC capacitor include peak power assist (eg LED flash), backup applications (eg solid state drives), energy harvesting systems and battery peak load levelling (eg tablet PCs, fuel cells, power tools).
Aluminium (EDLC) Super Capacitors
