KEMET 0.1F Supercapacitor -20 → +80% Tolerance, Supercap FC 5.5V dc, Surface Mount
- RS Stock No.:
- 789-8034
- Mfr. Part No.:
- FCS0H104ZFTBR24
- Brand:
- KEMET
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 789-8034
- Mfr. Part No.:
- FCS0H104ZFTBR24
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Capacitance | 0.1F | |
| Voltage | 5.5V dc | |
| Mounting Type | Surface Mount | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +70°C | |
| Diameter | 10.7mm | |
| Dimensions | 10.8 x 10.8 x 5.5mm | |
| Lead Pitch | 5mm | |
| Equivalent Series Resistance | 50Ω | |
| Series | Supercap FC | |
| Tolerance | -20 → +80% | |
| Product Diameter | 10.7mm | |
| Capacitor Family | Electric Double Layer | |
| Tolerance Minus | -20% | |
| Terminal Type | Surface Mount | |
| Depth | 5.5mm | |
| Tolerance Plus | +80% | |
Select all | ||
|---|---|---|
Brand KEMET | ||
Capacitance 0.1F | ||
Voltage 5.5V dc | ||
Mounting Type Surface Mount | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature +70°C | ||
Diameter 10.7mm | ||
Dimensions 10.8 x 10.8 x 5.5mm | ||
Lead Pitch 5mm | ||
Equivalent Series Resistance 50Ω | ||
Series Supercap FC | ||
Tolerance -20 → +80% | ||
Product Diameter 10.7mm | ||
Capacitor Family Electric Double Layer | ||
Tolerance Minus -20% | ||
Terminal Type Surface Mount | ||
Depth 5.5mm | ||
Tolerance Plus +80% | ||
- COO (Country of Origin):
- TH
FC Series SMT Super Capacitors
KEMET FC Supercapacitors are surface mount capacitors for use with high energy applications. These supercapacitors are designed especially for reflow soldering, allowing them to be attached to the printed circuit board directly.
Features
Wide range of temperature from −25°C to +70°C
Surface mount without holder
Operational Voltage: 3.5 to 5.5 V dc
Highly reliable against liquid leakage
Maintenance free
Surface mount without holder
Operational Voltage: 3.5 to 5.5 V dc
Highly reliable against liquid leakage
Maintenance free
Applications
Low voltage DC hold-up applications
Embedded microprocessor systems with flash memory.
Supercapacitors can be used like a secondary battery when applied in a DC circuit
Embedded microprocessor systems with flash memory.
Supercapacitors can be used like a secondary battery when applied in a DC circuit
Aluminium (EDLC) Super Capacitors
