Eaton 5 F Supercapacitor -10 to 30 % Tolerance, Supercap PHV 5.4 V dc, Through Hole

RS Stock No.:: 763-7848
Distrelec Article No.:: 301-96-511
Mfr. Part No.:: PHV-5R4V505-R
Brand:: Eaton

Eaton 5 F Supercapacitor -10 to 30 % Tolerance, Supercap PHV 5.4 V dc, Through Hole

Bulk discount available

Subtotal (1 unit)*

£11.47

(exc. VAT)

£13.76

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

Plus 5 unit(s) shipping from 16 March 2026
Plus 6 unit(s) shipping from 23 March 2026
Plus 200 unit(s) shipping from 09 April 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 - 24	£11.47
25 - 74	£10.90
75 - 149	£10.36
150 - 249	£8.62
250 +	£8.18

*price indicative

RS Stock No.:: 763-7848
Distrelec Article No.:: 301-96-511
Mfr. Part No.:: PHV-5R4V505-R
Brand:: Eaton

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Eaton
	Capacitance	5F
	Product Type	Supercapacitor
	Voltage	5.4 V dc
	Mount Type	Through Hole
	Packaging	Bag
	Lead Diameter	0.6mm
	Automotive Standard	No
	Polarity	Polar
	Diameter	21.3 mm
	Terminal Type	Solder
	Lead Pitch	5.3mm
	Leakage Current	28μA
	Minimum Operating Temperature	-40°C
	Equivalent Series Resistance ESR	70mΩ
	Pin Count	2
	Maximum Operating Temperature	65°C
	Lifetime	1000 h
	Depth	32.5mm
	Standards/Approvals	UL, RoHS
	Series	Supercap PHV
	Height	32.5mm
	Tolerance	-10 to 30 %
	Package/Case	Cylindrical
	Capacitor Family	Electric Double Layer

	Select all
	Brand Eaton
	Capacitance 5F
	Product Type Supercapacitor
	Voltage 5.4 V dc
	Mount Type Through Hole
	Packaging Bag
	Lead Diameter 0.6mm
	Automotive Standard No
	Polarity Polar
	Diameter 21.3 mm
	Terminal Type Solder
	Lead Pitch 5.3mm
	Leakage Current 28μA
	Minimum Operating Temperature -40°C
	Equivalent Series Resistance ESR 70mΩ
	Pin Count 2
	Maximum Operating Temperature 65°C
	Lifetime 1000 h
	Depth 32.5mm
	Standards/Approvals UL, RoHS
	Series Supercap PHV
	Height 32.5mm
	Tolerance -10 to 30 %
	Package/Case Cylindrical
	Capacitor Family Electric Double Layer

Eaton Supercapacitor, Ultra-Low ESR, 6V Surge Voltage - PHV Series - PHV-5R4V505-R

Lead the charge in your workplace with this Eaton supercapacitor. Thanks to its double-layer construction and super-high capacitance, you'll find it makes light work of collecting and storing large amounts of electricity up to 5F. You can use this to power up equipment as varied as handheld devices and hybrid vehicles. The product's Advanced carbon electrodes and current-collecting aluminium foil reliably resist corrosion so you GET minimal impedance and Rapid charging. As it has a wide tolerance range of -10% to +30%, you can count on accurately gauging this device's capacitance, even in abnormal conditions.

Features & Benefits

• Polarity clearly marked to support accurate installation

• Operating temperature range of -40°C to +65°C, so a safe bet in harsh environments

• Ultra-low ESR mean you GET minimal power loss with little energy wasted as heat

• Insulation withstands a surge voltage of 6V to boost user and equipment safety

Does this product contain any harmful substances?

You can rest assured this supercapacitor is free of lead and halogen, so it meets RoHS directives and contains only negligible amounts of any harmful substances.

Note

Eaton formerly known as Bussmann
