KYOCERA AVX 0.33 F Supercapacitor -10 to 30 % Tolerance, SCM 9 V, Through Hole

View all Supercapacitors
Bulk discount available

Subtotal (1 unit)*

£3.89

(exc. VAT)

£4.67

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 27 unit(s) ready to ship
  • Plus 14 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 9£3.89
10 - 44£3.79
45 - 89£3.70
90 +£3.60

*price indicative

RS Stock No.:
186-2202
Mfr. Part No.:
SCMR14L334SSBB0
Brand:
KYOCERA AVX
Find similar products by selecting one or more attributes.
Select all

Brand

KYOCERA AVX

Product Type

Supercapacitor

Capacitance

0.33F

Voltage

9 V

Mount Type

Through Hole

Packaging

Tray

Automotive Standard

No

Diameter

9.5 mm

Lead Diameter

0.6mm

Polarity

Polar

Lead Pitch

11.5mm

Terminal Type

Radial

Minimum Operating Temperature

-40°C

Pin Count

2

Equivalent Series Resistance ESR

2.85Ω

Maximum Operating Temperature

85°C

Series

SCM

Standards/Approvals

RoHS, UL, REACH

Height

16mm

Tolerance

-10 to 30 %

Capacitor Family

Supercapacitor

COO (Country of Origin):
CN
Capacitors or Double Layer Capacitors have rapidly become recognized, not only as an excellent compromise between “electronic” or “dielectric” capacitors such as ceramic, tantalum, film and aluminium electrolytic, and batteries, but also as a valuable technology for providing a unique combination of characteristics, particularly very high pulse power and capacitance densities.

The new series of cylindrical electrochemical double-layer capacitors offers excellent pulse power handling characteristics based on the combination of very high capacitance and very low ESR. Used by themselves or in conjunction with primary or secondary batteries, they provide extended back up time, longer battery life, and provide instantaneous power pulses as needed. Offers great solutions to Hold Up, Energy Harvesting, and Pulse Power Applications.

High pulse power capability

Low ESR

Low leakage current

Typical Applications

Camera flash systems

Energy harvesting

GSM/GSR pulse applications

UPS/Industrial

Wireless alarms

Remote metering

Scanners

Toys and games
