KEMET 4.7F Supercapacitor -20 → +80% Tolerance, Supercap FG 5.5V dc, Through Hole
- RS Stock No.:
- 135-6151
- Mfr. Part No.:
- FG0H475ZF
- Brand:
- KEMET
Bulk discount available
Subtotal (1 unit)*
£10.87
(exc. VAT)
£13.04
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 12 unit(s) ready to ship
- Plus 25 unit(s) shipping from 19 November 2025
- Plus 50 unit(s) shipping from 27 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £10.87 |
| 10 - 24 | £9.67 |
| 25 + | £9.17 |
*price indicative
- RS Stock No.:
- 135-6151
- Mfr. Part No.:
- FG0H475ZF
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Capacitance | 4.7F | |
| Voltage | 5.5V dc | |
| Mounting Type | Through Hole | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
| Diameter | 28.5mm | |
| Dimensions | 28.5 (Dia.) x 22mm | |
| Lead Pitch | 10.16mm | |
| Equivalent Series Resistance | 35Ω | |
| Series | Supercap FG | |
| Tolerance | -20 → +80% | |
| Terminal Type | Radial | |
| Dielectric Material Family | Electrical Double Layer | |
| Depth | 22mm | |
| Product Diameter | 28.5mm | |
| Lead Spacing | 10.16 mm | |
| Capacitor Family | Electric Double Layer | |
| Polarised | Polar | |
| Select all | ||
|---|---|---|
Brand KEMET | ||
Capacitance 4.7F | ||
Voltage 5.5V dc | ||
Mounting Type Through Hole | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
Diameter 28.5mm | ||
Dimensions 28.5 (Dia.) x 22mm | ||
Lead Pitch 10.16mm | ||
Equivalent Series Resistance 35Ω | ||
Series Supercap FG | ||
Tolerance -20 → +80% | ||
Terminal Type Radial | ||
Dielectric Material Family Electrical Double Layer | ||
Depth 22mm | ||
Product Diameter 28.5mm | ||
Lead Spacing 10.16 mm | ||
Capacitor Family Electric Double Layer | ||
Polarised Polar | ||
Supercap FG
KEMET FG series super capacitors are designed for high energy storage applications.supercapacitors can be used like a secondary battery when applied in a DC circuit. These supercapacitors are suited for use in low voltage DC hold-up applications such as
embedded microprocessor systems with flash memory.
embedded microprocessor systems with flash memory.
Features
Rectangular case
Wide range of temperature from −25°C to +70°C
Maintenance free
Highly reliable against liquid leakage
Leads can be transverse mounted
Wide range of temperature from −25°C to +70°C
Maintenance free
Highly reliable against liquid leakage
Leads can be transverse mounted
Aluminium (EDLC) Super Capacitors
