Igus 55 Teeth Spur Gear, 2 Module, 12 mm Bore Diam, 82.5 mm Pitch Diam, 27 mm Hub Diam
- RS Stock No.:
- 272-5663
- Mfr. Part No.:
- P360GM-ST-150-055-00-120-R
- Brand:
- Igus
Subtotal (1 unit)*
£38.64
(exc. VAT)
£46.37
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 09 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £38.64 |
*price indicative
- RS Stock No.:
- 272-5663
- Mfr. Part No.:
- P360GM-ST-150-055-00-120-R
- Brand:
- Igus
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Igus | |
| Product Type | Spur Gear | |
| Module | 2 | |
| Number of Teeth | 55 | |
| Bore Size | 12 mm | |
| Pitch Diameter | 82.5mm | |
| Hub Diameter | 27mm | |
| Face Width | 12mm | |
| Pressure Angle | 20° | |
| Series | P360GM | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand Igus | ||
Product Type Spur Gear | ||
Module 2 | ||
Number of Teeth 55 | ||
Bore Size 12 mm | ||
Pitch Diameter 82.5mm | ||
Hub Diameter 27mm | ||
Face Width 12mm | ||
Pressure Angle 20° | ||
Series P360GM | ||
Standards/Approvals RoHS | ||
The Igus igutek Spur gear with good tribological specifications provide a positive, constant speed drive to facilitate daily industrial operations. Its maintenance free properties reduce costs for lubrication and maintenance.
Very tough
Resistant to shock loads
