SKF 11 Tooth Rough Stock Bore Sprocket, PHS 06B-1BH11 06 B-1

RS Stock No.:: 267-9077
Mfr. Part No.:: PHS 06B-1BH11
Brand:: SKF

SKF 11 Tooth Rough Stock Bore Sprocket, PHS 06B-1BH11 06 B-1

View all Sprockets

Subtotal (1 unit)*

£1.65

(exc. VAT)

£1.98

(inc. VAT)

FREE delivery for orders over £50.00

Temporarily out of stock

3 unit(s) shipping from 23 February 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£1.65

*price indicative

RS Stock No.:: 267-9077
Mfr. Part No.:: PHS 06B-1BH11
Brand:: SKF

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	SKF
	Product Type	Sprocket
	Number of Teeth	11
	Bore Size	8 mm
	Bore Type	Rough Stock Bore
	Pitch Diameter	33.8mm
	Material	Steel
	Hub Diameter	22mm
	Sprocket Width	25mm
	Maximum Inside Diameter	8mm
	Acceptable Chain Type	06 B-1
	Standards/Approvals	EN, BS

	Select all
	Brand SKF
	Product Type Sprocket
	Number of Teeth 11
	Bore Size 8 mm
	Bore Type Rough Stock Bore
	Pitch Diameter 33.8mm
	Material Steel
	Hub Diameter 22mm
	Sprocket Width 25mm
	Maximum Inside Diameter 8mm
	Acceptable Chain Type 06 B-1
	Standards/Approvals EN, BS

Datasheet - PHS 06B-1BH11

COO (Country of Origin):: CN

SKF Sprocket, 8 mm Maximum Bore Diameter, 33.8mm Pitch Diameter - PHS 06B-1BH11

This simplex sprocket from SKF features a rough stock bore and a hub profile, connecting easily to the shaft. With precise dimensions and high-grade materials, this sprocket is designed to meet European standards. Available in various sises, it offers a comprehensive solution for different design requirements.

Features & Benefits

• High-grade steel construction with black oxide coating for durability

• Rough stock bore and hub profile for easy shaft connection

• Precise dimensions with a maximum bore diameter of 8mm and a pitch diameter of 33.8mm

• Suitable for British Standard Chain type 06B-1

• Sises up to 25 teeth feature hardened teeth for increased longevity

Applications

• Excellent for applications requiring a sprocket with a rough stock bore and hub profile

• Ideal for use in machinery and equipment that need to connect with a shaft securely

Can it accommodate different shaft sises?

Yes, it features a rough stock bore and hub profile to easily connect with various shaft dimensions.

Will it fit the British Standard Chain type 06B-1?

Yes, this sprocket is designed to reliablely fit the 06B-1 chain type.

Is it suitable for heavy-duty applications?

Yes, the high-quality steel construction ensures durability for demanding environments.
