Nichifu TMEDN Red Insulated Female Spade Connector, Receptacle, 0.27 x 0.03in Tab Size, 0.75mm² to 1.25mm²
- RS Stock No.:
- 490-4170
- Mfr. Part No.:
- HC TMEDN630809-FA-REDCLEAR
- Brand:
- Nichifu
Bulk discount available
Subtotal (1 pack of 5 units)*
£5.03
(exc. VAT)
£6.04
(inc. VAT)
FREE delivery for orders over £50.00
Limited stock
- 18 left, ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 - 49 | £5.03 | £1.006 |
| 50 + | £4.53 | £0.906 |
*price indicative
- RS Stock No.:
- 490-4170
- Mfr. Part No.:
- HC TMEDN630809-FA-REDCLEAR
- Brand:
- Nichifu
Specifications
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichifu | |
| Type | Receptacle | |
| Series | TMEDN | |
| Gender | Female | |
| Minimum Wire Size mm² | 0.75mm² | |
| Maximum Wire Size mm² | 1.25mm² | |
| Tab Thickness | 0.03in | |
| Tab Size | 0.27 x 0.03in | |
| Tab Width | 0.27in | |
| Insulation | Insulated | |
| Minimum Wire Size AWG | 18AWG | |
| Maximum Wire Size AWG | 16AWG | |
| Termination Method | Crimp | |
| Colour | Red | |
| Contact Material | Brass | |
| Insulation Material | Vinyl | |
| Overall Length | 0.846in | |
| Shrouded/Unshrouded | Shrouded | |
Select all | ||
|---|---|---|
Brand Nichifu | ||
Type Receptacle | ||
Series TMEDN | ||
Gender Female | ||
Minimum Wire Size mm² 0.75mm² | ||
Maximum Wire Size mm² 1.25mm² | ||
Tab Thickness 0.03in | ||
Tab Size 0.27 x 0.03in | ||
Tab Width 0.27in | ||
Insulation Insulated | ||
Minimum Wire Size AWG 18AWG | ||
Maximum Wire Size AWG 16AWG | ||
Termination Method Crimp | ||
Colour Red | ||
Contact Material Brass | ||
Insulation Material Vinyl | ||
Overall Length 0.846in | ||
Shrouded/Unshrouded Shrouded | ||
Non Compliant
- COO (Country of Origin):
- JP
Insertion connector terminal
Standards
UL, CSA
