Celduc SO8 Series Solid State Relay, 50 A Load, Panel Mount, 290 V ac Load, 32 V dc Control
- RS Stock No.:
- 917-4797
- Mfr. Part No.:
- SO885060
- Brand:
- Celduc
Subtotal (1 unit)*
£69.83
(exc. VAT)
£83.80
(inc. VAT)
FREE delivery for orders over £50.00
- 26 unit(s) ready to ship from another location
Units | Per unit |
|---|---|
| 1 - 4 | £69.83 |
| 5 - 9 | £67.04 |
| 10 + | £65.62 |
*price indicative
- RS Stock No.:
- 917-4797
- Mfr. Part No.:
- SO885060
- Brand:
- Celduc
Select all | Attribute | Value |
|---|---|---|
| Brand | Celduc | |
| Maximum Load Current | 50 A | |
| Mounting Type | Panel Mount | |
| Maximum Load Voltage | 290 V ac | |
| Minimum Load Voltage | 24 V ac | |
| Maximum Control Voltage | 32 V dc | |
| Minimum Control Voltage | 3.5 V dc | |
| Switching Type | Zero Cross | |
| Control Voltage Range | 3.5 → 32 V dc | |
| Minimum Load Current | 5 mA | |
| Range | SO8 | |
| Number of Poles | 1 | |
| Terminal Type | Screw | |
| Output Device | Thyristor | |
| Relay Type | AC | |
| Load Voltage Range | 24 → 290V ac | |
| Series | SO8 | |
| Maximum Turn On Time | 10ms | |
| Dimensions | 45 x 58.5 x 30mm | |
| Minimum Operating Temperature | -40°C | |
| Standards Met | CE | |
| Special Features | Zero-Cross AC Output, Designed for all types of loads on high voltage mains | |
| Operating Temperature Range | -40 → +100°C | |
| Length | 45mm | |
| Off State Leakage Current | 1 mA | |
| Height | 30mm | |
| Depth | 58.5mm | |
| Maximum Operating Temperature | +100°C | |
| Select all | ||
|---|---|---|
Brand Celduc | ||
Maximum Load Current 50 A | ||
Mounting Type Panel Mount | ||
Maximum Load Voltage 290 V ac | ||
Minimum Load Voltage 24 V ac | ||
Maximum Control Voltage 32 V dc | ||
Minimum Control Voltage 3.5 V dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 3.5 → 32 V dc | ||
Minimum Load Current 5 mA | ||
Range SO8 | ||
Number of Poles 1 | ||
Terminal Type Screw | ||
Output Device Thyristor | ||
Relay Type AC | ||
Load Voltage Range 24 → 290V ac | ||
Series SO8 | ||
Maximum Turn On Time 10ms | ||
Dimensions 45 x 58.5 x 30mm | ||
Minimum Operating Temperature -40°C | ||
Standards Met CE | ||
Special Features Zero-Cross AC Output, Designed for all types of loads on high voltage mains | ||
Operating Temperature Range -40 → +100°C | ||
Length 45mm | ||
Off State Leakage Current 1 mA | ||
Height 30mm | ||
Depth 58.5mm | ||
Maximum Operating Temperature +100°C | ||
- COO (Country of Origin):
- FR
Single-phase solid state relays, SO8 series
Voltage protection for input (transil) as well as output (VDR) for high immunity to interference.
Wide control range: 3 → 32 Vdc with regulated control current.
Green LED input display.
Solid state relays must be mounted on a heatsink.
