Celduc SK Series Solid State Relay, 25 A Load, PCB Mount, 280 V ac Load, 14 V dc Control
- RS Stock No.:
- 917-4743
- Mfr. Part No.:
- SKL10220
- Brand:
- Celduc
Subtotal (1 unit)*
£28.72
(exc. VAT)
£34.46
(inc. VAT)
FREE delivery for orders over £50.00
- 19 unit(s) ready to ship from another location
Units | Per unit |
|---|---|
| 1 - 4 | £28.72 |
| 5 - 9 | £27.57 |
| 10 + | £27.01 |
*price indicative
- RS Stock No.:
- 917-4743
- Mfr. Part No.:
- SKL10220
- Brand:
- Celduc
Select all | Attribute | Value |
|---|---|---|
| Brand | Celduc | |
| Maximum Load Current | 25 A | |
| Mounting Type | PCB Mount | |
| Maximum Load Voltage | 280 V ac | |
| Minimum Load Voltage | 12 V ac | |
| Maximum Control Voltage | 14 V dc | |
| Minimum Control Voltage | 4 V dc | |
| Switching Type | Zero Cross | |
| Control Voltage Range | 4 → 14 V dc | |
| Minimum Load Current | 5 mA | |
| Range | SK | |
| Number of Poles | 1 | |
| Terminal Type | PCB Pin | |
| Output Device | Thyristor | |
| Package Style | SIP4 | |
| Relay Type | AC | |
| Maximum Turn On Time | 10ms | |
| Series | SK | |
| Load Voltage Range | 12 → 280V ac | |
| Dimensions | 43.4 x 6.3 x 24.5mm | |
| Maximum Operating Temperature | +80°C | |
| Depth | 6.3mm | |
| Standards Met | cULus Recognized | |
| Special Features | Range for Printed Circuit Board for Mounting on an External Heatsink, Zero-Cross AC Output, DCB Technology | |
| Operating Temperature Range | -40 → +80°C | |
| Length | 43.4mm | |
| Off State Leakage Current | 1 mA | |
| Height | 24.5mm | |
| Minimum Operating Temperature | -40°C | |
Select all | ||
|---|---|---|
Brand Celduc | ||
Maximum Load Current 25 A | ||
Mounting Type PCB Mount | ||
Maximum Load Voltage 280 V ac | ||
Minimum Load Voltage 12 V ac | ||
Maximum Control Voltage 14 V dc | ||
Minimum Control Voltage 4 V dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 4 → 14 V dc | ||
Minimum Load Current 5 mA | ||
Range SK | ||
Number of Poles 1 | ||
Terminal Type PCB Pin | ||
Output Device Thyristor | ||
Package Style SIP4 | ||
Relay Type AC | ||
Maximum Turn On Time 10ms | ||
Series SK | ||
Load Voltage Range 12 → 280V ac | ||
Dimensions 43.4 x 6.3 x 24.5mm | ||
Maximum Operating Temperature +80°C | ||
Depth 6.3mm | ||
Standards Met cULus Recognized | ||
Special Features Range for Printed Circuit Board for Mounting on an External Heatsink, Zero-Cross AC Output, DCB Technology | ||
Operating Temperature Range -40 → +80°C | ||
Length 43.4mm | ||
Off State Leakage Current 1 mA | ||
Height 24.5mm | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- FR
SKL Series Solid State Power Relays
This range is specially designed for heating installations, but also for incandescent lamps and motors.
Very high resistance to overload currents.
