Kudom 60 A Solid State Relay, Zero Cross, Panel Mount, SCR, 530 V ac Maximum Load

  • RS Stock No. 102-5553
  • Mfr. Part No. KSQC480D60-C
  • Brand Kudom
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

KSQC Series 3-Phase SSR

Kudom KSQC series smart 3 phase AC output solid state relay with internal MCU control unit that provides over temperature, SCR fault, load disconnection and phase-lack detection. KSQC relays have a control voltage of 10 V dc to 32 V dc with load currents at 25A, 40A, 60A or 80A available. Wide load voltage range of 48 V ac to 660 V ac. Featuring an alarm contact option and LED indication.

Zero switching or random-on
SCR failure detection function
Load disconnection detection
Over temperature protection
Auxiliary contact option
Internal MOV/RC protection circuit
RoHS compliant

Zero Voltage Relays

Note

Temperature can affect current rating; please consult the data sheet for potential derating.

Specifications
Attribute Value
Maximum Load Current 60 A
Mounting Type Panel Mount
Minimum Load Voltage 48 V ac
Maximum Load Voltage 530 V ac
Minimum Control Voltage 10 V dc
Maximum Control Voltage 32 V dc
Switching Type Zero Cross
Terminal Type Screw
Output Device SCR
Maximum Turn On Time 35 ms
Dimensions 105 x 78 x 38mm
Control Voltage Range 10 → 32 V dc
Operating Temperature Range -30 → +80°C
Load Voltage Range 48 → 530V ac
Off State Leakage Current 5 mA
Length 105mm
Height 38mm
Standards Met CE
Depth 78mm
Relay Type Three Phase
Special Features Fault Indication Function, Internal RC/MOV Protection Circuit, Load Disconnection Detection Function, Over Temperature Protection, Phase-Lack Detection Function, SCR Failure Detection Function
Available to back order for despatch 12/03/2020
Price Each
£ 230.65
(exc. VAT)
£ 276.78
(inc. VAT)
Units
Per unit
1 +
£230.65
