i-Autoc Solid State Relay, 2 A Load, PCB Mount, 280 V ac Load, 6 V dc Control
- RS Stock No.:
- 102-5528
- Mfr. Part No.:
- KSMA240D2-5
- Brand:
- i-Autoc
Available to back order for despatch when stock is available
Added
Price Each
£7.09
(exc. VAT)
£8.51
(inc. VAT)
| Units | Per unit |
| 1 + | £7.09 |
- RS Stock No.:
- 102-5528
- Mfr. Part No.:
- KSMA240D2-5
- Brand:
- i-Autoc
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
KSMA Series Single Phase SSR
PCB Mounted
Opto-isolation
Dielectric strength 2500 Vrms
RoHS compliant
Opto-isolation
Dielectric strength 2500 Vrms
RoHS compliant
I-Autoc KSMA series single phase AC output PCB mount solid state relay. KSMA relays have various control voltage options available with a load current at 1A or 2A. Suitable for high density PCB mounted or PLC control applications.
I-Autoc PCB Mounting SSR
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 2 A |
| Mounting Type | PCB Mount |
| Maximum Load Voltage | 280 V ac |
| Minimum Load Voltage | 48 V ac |
| Maximum Control Voltage | 6 V dc |
| Minimum Control Voltage | 4 V dc |
| Switching Type | Zero Cross |
| Control Voltage Range | 4 → 6 V dc |
| Minimum Load Current | 0.1 A |
| Terminal Type | PCB Pin |
| Relay Type | Single Phase |
| Load Voltage Range | 48 → 280V ac |
| Maximum Turn On Time | 1 (+1/2 cycle) ms |
| Dimensions | 28.2 x 5.2 x 15mm |
| Operating Temperature Range | -30 → +80°C |
| Special Features | COMS Drive Compatible, Optoelectronic Isolation, TTL |
| Standards Met | CE, cULus |
| Height | 15mm |
| Off State Leakage Current | 1.5 mA |
| Depth | 5.2mm |
| Length | 28.2mm |
