Vishay Single Layer Ceramic Capacitor (SLCC) 750pF 15kV dc ±20% T3M (N4700) Dielectric, 615R, Through Hole +105°C Max
- RS Stock No.:
- 831-3341
- Mfr. Part No.:
- 615R150GATT75
- Brand:
- Vishay
Discontinued
- RS Stock No.:
- 831-3341
- Mfr. Part No.:
- 615R150GATT75
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Capacitance | 750pF | |
| Voltage | 15kV dc | |
| Mounting Type | Through Hole | |
| Series | 615R | |
| Tolerance | ±20% | |
| Dielectric | T3M (N4700) | |
| Diameter | 27mm | |
| Depth | 10.9mm | |
| Dimensions | 27 (Dia.) x 59mm | |
| Maximum Operating Temperature | +105°C | |
| Minimum Operating Temperature | -25°C | |
| Terminal Type | Radial | |
| Dielectric Material Family | Ceramic | |
| Capacitor Family | Single Layer | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Capacitance 750pF | ||
Voltage 15kV dc | ||
Mounting Type Through Hole | ||
Series 615R | ||
Tolerance ±20% | ||
Dielectric T3M (N4700) | ||
Diameter 27mm | ||
Depth 10.9mm | ||
Dimensions 27 (Dia.) x 59mm | ||
Maximum Operating Temperature +105°C | ||
Minimum Operating Temperature -25°C | ||
Terminal Type Radial | ||
Dielectric Material Family Ceramic | ||
Capacitor Family Single Layer | ||
- COO (Country of Origin):
- CZ
615R Series Ceramic Capacitors
The Vishay 615R series of high voltage ceramic disc capacitors are designed for use in high power applications where stability is required. The capacitors consist of a ceramic disc, with both sides silver plated and coated with a flame retardant epoxy resin.
Features
High capacitance with small size
Low losses
High reliability
Tinned copper radial leads"
Low losses
High reliability
Tinned copper radial leads"
Applications
TV and monitors
DC and pulse high voltage
X-ray equipment
Switched Mode Power Supply ( SMPS)
DC and pulse high voltage
X-ray equipment
Switched Mode Power Supply ( SMPS)
X7R Dielectric
