RS PRO Single Layer Ceramic Capacitor (SLCC) 47pF 6kV dc ±5% SL Dielectric, Through Hole +125°C Max Op. Temp.
- RS Stock No.:
- 180-5135
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 pack of 100 units)*
£6.90
(exc. VAT)
£8.30
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 400 unit(s) shipping from 01 December 2025
- Plus 3,700 unit(s) shipping from 08 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 100 - 400 | £0.069 | £6.90 |
| 500 + | £0.058 | £5.80 |
*price indicative
- RS Stock No.:
- 180-5135
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Capacitance | 47pF | |
| Voltage | 6kV dc | |
| Mounting Type | Through Hole | |
| Tolerance | ±5% | |
| Dielectric | SL | |
| Diameter | 8.5mm | |
| Suppression Class | Class I | |
| Tolerance Minus | -5% | |
| Terminal Type | Solder | |
| Minimum Operating Temperature | -25°C | |
| Capacitor Family | Single Layer | |
| Maximum Operating Temperature | +125°C | |
| Tolerance Plus | +5% | |
| Dielectric Material Family | Ceramic | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Capacitance 47pF | ||
Voltage 6kV dc | ||
Mounting Type Through Hole | ||
Tolerance ±5% | ||
Dielectric SL | ||
Diameter 8.5mm | ||
Suppression Class Class I | ||
Tolerance Minus -5% | ||
Terminal Type Solder | ||
Minimum Operating Temperature -25°C | ||
Capacitor Family Single Layer | ||
Maximum Operating Temperature +125°C | ||
Tolerance Plus +5% | ||
Dielectric Material Family Ceramic | ||
- COO (Country of Origin):
- TW
Capacitance has linear temperature coefficient
Capacitance high stability
Epoxy Coating for 1KV, 2KV, 3KV, 6KV parts
Halogen free products are available
Low lost at wide range of frequency
Capacitance high stability
Epoxy Coating for 1KV, 2KV, 3KV, 6KV parts
Halogen free products are available
Low lost at wide range of frequency
