RS PRO Single Layer Ceramic Capacitor 1 nF 6 kV dc ±10 % Y5P Dielectric, YP602, Through Hole 85 °C Max Op. Temp.
- RS Stock No.:
- 180-4847
- Brand:
- RS PRO
Subtotal (1 bag of 1000 units)*
£61.00
(exc. VAT)
£73.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 21,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 1000 + | £0.061 | £61.00 |
*price indicative
- RS Stock No.:
- 180-4847
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Capacitance | 1nF | |
| Product Type | Single Layer Ceramic Capacitor | |
| Voltage | 6 kV dc | |
| Mount Type | Through Hole | |
| Packaging | Bulk | |
| Series | YP602 | |
| Tolerance | ±10 % | |
| Dielectric | Y5P | |
| Automotive Standard | No | |
| Pin Count | 2 | |
| Minimum Operating Temperature | -25°C | |
| Standards/Approvals | RoHS, UL 94 V-0 | |
| Length | 20mm | |
| Diameter | 12 mm | |
| Suppression Class | Class II | |
| Terminal Type | Solder | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Capacitance 1nF | ||
Product Type Single Layer Ceramic Capacitor | ||
Voltage 6 kV dc | ||
Mount Type Through Hole | ||
Packaging Bulk | ||
Series YP602 | ||
Tolerance ±10 % | ||
Dielectric Y5P | ||
Automotive Standard No | ||
Pin Count 2 | ||
Minimum Operating Temperature -25°C | ||
Standards/Approvals RoHS, UL 94 V-0 | ||
Length 20mm | ||
Diameter 12 mm | ||
Suppression Class Class II | ||
Terminal Type Solder | ||
Maximum Operating Temperature 85°C | ||
- COO (Country of Origin):
- TW
Capacitance has non-linear temperature coefficient
Large capacitance in small size
Epoxy Coating for 2 KV parts
Halogen free products are available
Wide range of general purposes applications
