Panasonic Surface Mount Signal Relay, 12V dc Coil, 1A Switching Current, DPDT
- RS Stock No.:
- 815-4938
- Mfr. Part No.:
- TXS2-12V
- Brand:
- Panasonic
122 In stock - FREE next working day delivery available
37 available from Europe for delivery within 2 working day(s).
Price Each
£3.62
(exc. VAT)
£4.34
(inc. VAT)
Units | Per unit |
---|---|
1 - 24 | £3.62 |
25 - 49 | £3.03 |
50 - 99 | £2.87 |
100 - 249 | £2.72 |
250 + | £2.43 |
- RS Stock No.:
- 815-4938
- Mfr. Part No.:
- TXS2-12V
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
TX-S Series
50mW nominal operating power
Outstanding surge resistance
High contact reliability
Low thermal electromotive force
Outstanding surge resistance
High contact reliability
Low thermal electromotive force
Specifications
Attribute | Value |
---|---|
Coil Voltage | 12V dc |
Contact Configuration | DPDT |
Mounting Type | Surface Mount |
Maximum Switching Current DC | 1 A |
Maximum Switching Voltage DC | 110V |
Maximum Switching Power DC | 30 W |
Series | G6K |
Latching | No |
Length | 15mm |
Depth | 7.4mm |
Height | 8.2mm |
Dimensions | 15 x 8.2 x 7.4mm |
Terminal Type | Through Hole |
Switching Current | 1A |
Number of Poles | 2 |
Application | Domestic Appliances, General Purpose, Medical Equipment, Safety |
Isolation Coil To Contact | 1.5kV |
Coil Resistance | 2800Ω |
Life | 2 x 10^5 (Electrical) Operations, 5 x 10^7 (Mechanical) Operations |
Coil Power | 50mW |
Features | Outstanding Surge Resistance, Sealed Construction Allows Automatic Washing, |
Minimum Operating Temperature | -40°C |
Maximum Operating Temperature | +85°C |
Contact Material | Gold Plated |
Operating Temperature Range | -40 → +85°C |
