TE Connectivity PCB Mount Signal Relay, 2.5V dc Coil, 2A Switching Current, DPDT
- RS Stock No.:
- 276-3876
- Mfr. Part No.:
- IM02JR 1-1462037-1
- Brand:
- TE Connectivity
Bulk discount available
Subtotal (1 unit)*
£2.36
(exc. VAT)
£2.83
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 375 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £2.36 |
| 10 - 99 | £2.26 |
| 100 - 249 | £2.14 |
| 250 - 499 | £2.02 |
| 500 + | £1.95 |
*price indicative
- RS Stock No.:
- 276-3876
- Mfr. Part No.:
- IM02JR 1-1462037-1
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Coil Voltage | 2.5V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | PCB Mount | |
| Number of Coils | Single | |
| Maximum Switching Current DC | 2 A | |
| Maximum Switching Voltage AC | 250V ac | |
| Maximum Switching Voltage DC | 220V dc | |
| Series | Axicom IM | |
| Latching | No | |
| Length | 10mm | |
| Depth | 6mm | |
| Height | 5.65mm | |
| Dimensions | 10 x 6 x 5.65mm | |
| Terminal Type | Surface Mount | |
| Number of Poles | 2 | |
| Switching Current | 2A | |
| Features | J Leg | |
| Coil Resistance | 145 Ω | |
| Operating Temperature Range | -40 → 85°C | |
| Coil Power | 140mW | |
| Contact Material | Gold Plated | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Coil Voltage 2.5V dc | ||
Contact Configuration DPDT | ||
Mounting Type PCB Mount | ||
Number of Coils Single | ||
Maximum Switching Current DC 2 A | ||
Maximum Switching Voltage AC 250V ac | ||
Maximum Switching Voltage DC 220V dc | ||
Series Axicom IM | ||
Latching No | ||
Length 10mm | ||
Depth 6mm | ||
Height 5.65mm | ||
Dimensions 10 x 6 x 5.65mm | ||
Terminal Type Surface Mount | ||
Number of Poles 2 | ||
Switching Current 2A | ||
Features J Leg | ||
Coil Resistance 145 Ω | ||
Operating Temperature Range -40 → 85°C | ||
Coil Power 140mW | ||
Contact Material Gold Plated | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -40°C | ||
The TE Connectivity Axicom IM signal relay are part of our smallest types of electromechanical relays, offer a wide and deep range of variations suitable for many applications. The IM series are equipped with 2 changeover contacts in both monostable or bistable versions, available in multiple coil solutions, performance types and pin layouts.
High mechanical shock resistance
Low coil power consumption
Low coil power consumption
