Hongfa Europe GMBH PCB Mount Signal Relay, 24V dc Coil, 2A Switching Current, SPDT
- RS Stock No.:
- 176-2932
- Mfr. Part No.:
- HFD27/024-H
- Brand:
- Hongfa Europe GMBH
Subtotal (1 pack of 5 units)*
£9.70
(exc. VAT)
£11.65
(inc. VAT)
FREE delivery for orders over £50.00
- 490 unit(s) ready to ship
- Plus 70 unit(s) ready to ship from another location
- Plus 1,210 unit(s) shipping from 28 October 2025
Units | Per unit | Per Pack* |
---|---|---|
5 + | £1.94 | £9.70 |
*price indicative
- RS Stock No.:
- 176-2932
- Mfr. Part No.:
- HFD27/024-H
- Brand:
- Hongfa Europe GMBH
Select all | Attribute | Value |
---|---|---|
Brand | Hongfa Europe GMBH | |
Coil Voltage | 24V dc | |
Contact Configuration | SPDT | |
Mounting Type | PCB Mount | |
Maximum Switching Current AC | 2 A | |
Maximum Switching Current DC | 2 A | |
Maximum Switching Voltage AC | 240V | |
Maximum Switching Voltage DC | 120V | |
Maximum Switching Power DC | 60 W | |
Series | HFD27 | |
Length | 20.2mm | |
Latching | No | |
Depth | 10mm | |
Height | 11.5mm | |
Dimensions | 20.2 x 10 x 11.5mm | |
Terminal Type | PCB Pin | |
Switching Current | 2A | |
Number of Poles | 2 | |
Contact Material | Gold Plated | |
Operating Temperature Range | -40 → +85°C | |
Life | 1 x 10^8 cycles | |
Maximum Switching Power AC | 125VA | |
Maximum Operating Temperature | +85°C | |
Coil Power | 150mW | |
Electrical Life | 100000 Operations | |
Isolation Coil To Contact | 1kV ac | |
Features | High Switching Capability, Bifurcated Contacts, Epoxy Sealed For Automatic Wave Soldering And Cleaning | |
Relay Switching Classification | Subminiature DIP Relay | |
Coil Resistance | 3800Ω | |
Minimum Operating Temperature | -40°C | |
Select all | ||
---|---|---|
Brand Hongfa Europe GMBH | ||
Coil Voltage 24V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Maximum Switching Current AC 2 A | ||
Maximum Switching Current DC 2 A | ||
Maximum Switching Voltage AC 240V | ||
Maximum Switching Voltage DC 120V | ||
Maximum Switching Power DC 60 W | ||
Series HFD27 | ||
Length 20.2mm | ||
Latching No | ||
Depth 10mm | ||
Height 11.5mm | ||
Dimensions 20.2 x 10 x 11.5mm | ||
Terminal Type PCB Pin | ||
Switching Current 2A | ||
Number of Poles 2 | ||
Contact Material Gold Plated | ||
Operating Temperature Range -40 → +85°C | ||
Life 1 x 10^8 cycles | ||
Maximum Switching Power AC 125VA | ||
Maximum Operating Temperature +85°C | ||
Coil Power 150mW | ||
Electrical Life 100000 Operations | ||
Isolation Coil To Contact 1kV ac | ||
Features High Switching Capability, Bifurcated Contacts, Epoxy Sealed For Automatic Wave Soldering And Cleaning | ||
Relay Switching Classification Subminiature DIP Relay | ||
Coil Resistance 3800Ω | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- CN
Hongfa DPDT Non-Latching Relay
Features and Benefits
• High Sensitive coil power of 150mW
• Service temperature range between -40°C and 85°C
• Isolation voltage between coil and contact is 1.5KVAC
• Bifurcated contacts
• Epoxy sealed for automatic wave soldering and cleaning
• Available in DIP terminal type
• Matching 16 pin IC socket
Applications
• Automotive industry
