    Hongfa Europe GMBH PCB Mount Signal Relay, 5V dc Coil, 2A Switching Current, DPDT

    View all Signal Relays

    Subtotal (1 pack of 5 units)*

    £9.42

    (exc. VAT)

    £11.305

    (inc. VAT)

    Add to Basket
    Select or type quantity
    In Stock
    • 310 unit(s) ready to ship
    • Plus 135 unit(s) ready to ship from another location
    • Plus 210 unit(s) shipping from 18 July 2025
    Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
    Units
    Per unit
    Per Pack*
    5 +£1.884£9.42

    *price indicative

    RS Stock No.:
    176-2905
    Mfr. Part No.:
    HFD27/005-H
    Brand:
    Hongfa Europe GMBH
    Find similar products by selecting one or more attributes.
    Select all

    Brand

    Hongfa Europe GMBH

    Coil Voltage

    5V dc

    Contact Configuration

    DPDT

    Mounting Type

    PCB Mount

    Maximum Switching Current AC

    2 A

    Maximum Switching Current DC

    2 A

    Maximum Switching Voltage AC

    240V

    Maximum Switching Voltage DC

    120V

    Maximum Switching Power DC

    60 W

    Series

    HFD27

    Latching

    No

    Length

    20mm

    Depth

    10mm

    Height

    11.5mm

    Dimensions

    20.2 x 10 x 11.5mm

    Terminal Type

    PCB Pin

    Switching Current

    2A

    Number of Poles

    2

    Coil Power

    150mW

    Maximum Operating Temperature

    +85°C

    Isolation Coil To Contact

    1kV rms

    Life

    1 x 10^8 cycles

    Maximum Switching Power AC

    125VA

    Relay Switching Classification

    Subminiature DIP Relay

    Coil Resistance

    167Ω

    Operating Temperature Range

    -40 → +85°C

    Features

    High Switching Capability, Bifurcated Contacts, Epoxy Sealed For Automatic Wave Soldering And Cleaning

    Contact Material

    Gold Plated

    Electrical Life

    100000 Operations

    Minimum Operating Temperature

    -40°C
