Ruland Collar, One Piece, Clamp Screw, OD 60 mm OD, W 15 mm, Anodised Aluminium
- RS Stock No.:
- 603-468
- Mfr. Part No.:
- FHD-MCL-38-AN
- Brand:
- Ruland
Subtotal (1 unit)*
£85.90
(exc. VAT)
£103.08
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £85.90 |
*price indicative
- RS Stock No.:
- 603-468
- Mfr. Part No.:
- FHD-MCL-38-AN
- Brand:
- Ruland
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Ruland | |
| Bore Size | 38 mm | |
| Product Type | Collar | |
| One/Two Piece | One Piece | |
| Material | Anodised Aluminium | |
| Single/Double Wide | Single Wide | |
| Outside Diameter | 60 mm | |
| Fastening | Clamp Screw | |
| Width | 15 mm | |
| Finish | Anodised | |
| Bore Type | Clamp Style | |
| Series | FHD-MCL | |
| Standards/Approvals | RoHs and Reach | |
| Select all | ||
|---|---|---|
Brand Ruland | ||
Bore Size 38 mm | ||
Product Type Collar | ||
One/Two Piece One Piece | ||
Material Anodised Aluminium | ||
Single/Double Wide Single Wide | ||
Outside Diameter 60 mm | ||
Fastening Clamp Screw | ||
Width 15 mm | ||
Finish Anodised | ||
Bore Type Clamp Style | ||
Series FHD-MCL | ||
Standards/Approvals RoHs and Reach | ||
The Ruland One piece shaft collar has drilled holes for mounting shaft collars to sprockets, pulleys, metallic plates, or other components. Drilled holes give the user flexibility to choose inch or metric mounting hardware that best suits the application. The clamp style design does not mar the shaft, is easy to remove, and is indefinitely adjustable.
RoHS3 and REACH compliant
High grade 2024 aluminium with an anodized finish
Forged screws test beyond DIN 912 12.9 standards
