TE Connectivity Straight Male 4 way M12 to Right Angle Female 4 way M12 Sensor Actuator Cable, 2m
- RS Stock No.:
- 238-4572
- Mfr. Part No.:
- T4152699L14-020
- Brand:
- TE Connectivity
Subtotal (1 bag of 25 units)*
£750.025
(exc. VAT)
£900.025
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 22 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 25 + | £30.001 | £750.03 |
*price indicative
- RS Stock No.:
- 238-4572
- Mfr. Part No.:
- T4152699L14-020
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | M12 L-Code | |
| Cross Sectional Area | 2.5 mm² | |
| Sheath Material | Nylon | |
| Length | 2m | |
| Sheath Colour | Black | |
| Connector 1 Gender | Male | |
| Connector 1 Number of Contacts | 4 | |
| Connector 1 Orientation | Straight | |
| Connector 1 | M12 | |
| Connector 2 Orientation | Right Angle | |
| Connector 2 Number of Contacts | 4 | |
| Connector 2 Gender | Female | |
| Connector 2 Housing Gender | Female | |
| Connector 2 | M12 | |
| Coding | L | |
| Current Rating | 16 A | |
| Voltage Rating | 63 V | |
| IP Rating | IP67 | |
| Number of Strands | 124 | |
| Standards Met | UL | |
| Maximum Operating Temperature | +85°C | |
| Insulation Material | PVC | |
| Conductor Material | Copper | |
| Connector 1 Housing Gender | Male | |
| Minimum Operating Temperature | -25°C | |
| Outer Diameter | 9.4mm | |
| American Wire Gauge | 14 AWG | |
Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series M12 L-Code | ||
Cross Sectional Area 2.5 mm² | ||
Sheath Material Nylon | ||
Length 2m | ||
Sheath Colour Black | ||
Connector 1 Gender Male | ||
Connector 1 Number of Contacts 4 | ||
Connector 1 Orientation Straight | ||
Connector 1 M12 | ||
Connector 2 Orientation Right Angle | ||
Connector 2 Number of Contacts 4 | ||
Connector 2 Gender Female | ||
Connector 2 Housing Gender Female | ||
Connector 2 M12 | ||
Coding L | ||
Current Rating 16 A | ||
Voltage Rating 63 V | ||
IP Rating IP67 | ||
Number of Strands 124 | ||
Standards Met UL | ||
Maximum Operating Temperature +85°C | ||
Insulation Material PVC | ||
Conductor Material Copper | ||
Connector 1 Housing Gender Male | ||
Minimum Operating Temperature -25°C | ||
Outer Diameter 9.4mm | ||
American Wire Gauge 14 AWG | ||
- COO (Country of Origin):
- CN
The TE Connectivity M12 Power L-code cable assembly are an extension of the current M12 IEC standard and have been selected by PROFIBUS and PROFINET International as the standard for 24-volt power supply systems used in PROFINET devices. The M12 power cable assembly are available in both male and female connectors and suitable for every purpose with its conductor size from 1.5 mm² up to 2.5 mm² allowing for a more compact build of a high-power solutions for automation devices. The L-coding version is designed for DC power supplies with 63 V DC / 16 A, where a high current and low voltage is required making ideal for fieldbus Ethernet I/O boxes, Ethernet systems, network Devices, motors and drives and valve applications.
Unit remains protected and fully operational in most industrial applications
Secured signal connections and data transmission
Protection against mismatching with coded pin connector patterns
PNO approved for immediate implementation into PROFINET standard and embracing miniaturization of distribution boxes
One stop shop solution with broad product portfolio with cable jacket colours and material options
Secured signal connections and data transmission
Protection against mismatching with coded pin connector patterns
PNO approved for immediate implementation into PROFINET standard and embracing miniaturization of distribution boxes
One stop shop solution with broad product portfolio with cable jacket colours and material options
