ifm electronic Female 4 way M12 to Male 4 way M12 Sensor Actuator Cable, 20m
- RS Stock No.:
- 183-2805
- Mfr. Part No.:
- EVF534
- Brand:
- ifm electronic
Available to back order for despatch 17/06/2024
Added
Price Each
£120.54
(exc. VAT)
£144.65
(inc. VAT)
| Units | Per unit |
| 1 + | £120.54 |
- RS Stock No.:
- 183-2805
- Mfr. Part No.:
- EVF534
- Brand:
- ifm electronic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- PL
Product Details
For set-up, parameter setting and process data exchange of the vision sensors the operating software is used. For the parameter setting and process interface, two protocols are available: TCP/IP and EtherNet/IP. An EtherNet patch cable is used to connect the sensor and the processor.
For use in sanitary and wet areas in the food industry
Cable jacket made of halogen-free and flame-retardant material
With robust M12 connector Industrial Ethernet
Wide operating temperature range and high protection rating
Shielded cable for good electromagnetic immunity
Cable jacket made of halogen-free and flame-retardant material
With robust M12 connector Industrial Ethernet
Wide operating temperature range and high protection rating
Shielded cable for good electromagnetic immunity
Specifications
Attribute | Value |
|---|---|
| Series | EVF |
| Cross Sectional Area | 0.34 mm² |
| Number of Cores | 4 |
| Length | 20m |
| Sheath Material | mPPE |
| Sheath Colour | Grey |
| Connector 1 | M12 |
| Connector 1 Number of Contacts | 4 |
| Connector 1 Gender | Female |
| Connector 2 Housing Gender | Female |
| Connector 2 Gender | Male |
| Connector 2 Number of Contacts | 4 |
| Connector 2 | M12 |
| Voltage Rating | 30, 60 V |
| Current Rating | 4 A |
| IP Rating | IP65, IP67, IP68, IP69K |
| Minimum Bend Radius | 15 x cable diameter |
| Operating Temperature Range | -25 → +80 °C |
| Outer Diameter | 6.5mm |
| Fire Behaviour | Halogen Free |
| Connector 1 Housing Gender | Male |
| American Wire Gauge | 22 AWG |
