Bulgin Straight Female 5 way M8 to Unterminated Sensor Actuator Cable, 1m
- RS Stock No.:
- 144-6742
- Distrelec Article No.:
- 303-26-782
- Mfr. Part No.:
- PXPPVC08FBF05BCL010PVC
- Brand:
- Bulgin
Save 12% when you buy 50 units
Subtotal (1 unit)*
£20.56
(exc. VAT)
£24.67
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 51 unit(s) ready to ship
- Plus 7 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £20.56 |
| 5 - 24 | £19.16 |
| 25 - 49 | £18.61 |
| 50 + | £18.05 |
*price indicative
- RS Stock No.:
- 144-6742
- Distrelec Article No.:
- 303-26-782
- Mfr. Part No.:
- PXPPVC08FBF05BCL010PVC
- Brand:
- Bulgin
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Series | M8 | |
| Number of Cores | 5 | |
| Sheath Colour | Black | |
| Length | 1m | |
| Sheath Material | PUR | |
| Connector 1 Orientation | Straight | |
| Connector 1 | M8 | |
| Connector 1 Gender | Female | |
| Connector 1 Number of Contacts | 5 | |
| Connector 2 | Unterminated | |
| Coding | B | |
| Shielded/Unshielded | Unshielded | |
| Voltage Rating | 30 V | |
| Current Rating | 1.5 A | |
| IP Rating | IP67 | |
| Connector 1 Housing Gender | Female | |
| Conductor Material | Phosphor Bronze | |
| Cable Shape | Single Core | |
| Outer Diameter | 3 → 3.5mm | |
| Minimum Operating Temperature | -25°C | |
| Operating Temperature Range | -25 → +80 °C | |
| Maximum Operating Temperature | +80°C | |
| Conductor Resistance | <10 mΩ | |
Select all | ||
|---|---|---|
Brand Bulgin | ||
Series M8 | ||
Number of Cores 5 | ||
Sheath Colour Black | ||
Length 1m | ||
Sheath Material PUR | ||
Connector 1 Orientation Straight | ||
Connector 1 M8 | ||
Connector 1 Gender Female | ||
Connector 1 Number of Contacts 5 | ||
Connector 2 Unterminated | ||
Coding B | ||
Shielded/Unshielded Unshielded | ||
Voltage Rating 30 V | ||
Current Rating 1.5 A | ||
IP Rating IP67 | ||
Connector 1 Housing Gender Female | ||
Conductor Material Phosphor Bronze | ||
Cable Shape Single Core | ||
Outer Diameter 3 → 3.5mm | ||
Minimum Operating Temperature -25°C | ||
Operating Temperature Range -25 → +80 °C | ||
Maximum Operating Temperature +80°C | ||
Conductor Resistance <10 mΩ | ||
