Intelligent Memory IME2532SDBETG-6I, SDRAM 256Mbit Surface Mount, 166MHz, 90-Pin FBGA
- RS Stock No.:
- 588-606
- Mfr. Part No.:
- IME2532SDBETG-6I
- Brand:
- Intelligent Memory
Subtotal (1 unit)*
£5.39
(exc. VAT)
£6.47
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 20 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £5.39 |
*price indicative
- RS Stock No.:
- 588-606
- Mfr. Part No.:
- IME2532SDBETG-6I
- Brand:
- Intelligent Memory
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Intelligent Memory | |
Memory Size | 256Mbit | |
SDRAM Class | SDR | |
Organisation | 8M x 32 | |
Data Rate | 166MHz | |
Data Bus Width | 16bit | |
Maximum Random Access Time | 6ns | |
Mounting Type | Surface Mount | |
Package Type | FBGA | |
Pin Count | 90 | |
Minimum Operating Temperature | -40 °C | |
Minimum Operating Supply Voltage | 3V | |
Maximum Operating Supply Voltage | 3.6 V | |
Maximum Operating Temperature | 85 °C | |
Select all | ||
---|---|---|
Brand Intelligent Memory | ||
Memory Size 256Mbit | ||
SDRAM Class SDR | ||
Organisation 8M x 32 | ||
Data Rate 166MHz | ||
Data Bus Width 16bit | ||
Maximum Random Access Time 6ns | ||
Mounting Type Surface Mount | ||
Package Type FBGA | ||
Pin Count 90 | ||
Minimum Operating Temperature -40 °C | ||
Minimum Operating Supply Voltage 3V | ||
Maximum Operating Supply Voltage 3.6 V | ||
Maximum Operating Temperature 85 °C | ||
- COO (Country of Origin):
- TW
The Intelligent Memory Four bank Synchronous DRAM is organized as 4 banks x 2Mbit x 32. It achieves high-speed data transfer rates up to 166 MHz by employing a chip architecture that prefetches multiple bits and synchronizes the output data to the system clock, ensuring efficient and reliable performance.
Power down mode
Auto refresh and self refresh
Automatic and controlled precharge command
Auto refresh and self refresh
Automatic and controlled precharge command
