Vishay 200V 3A, Rectifier Diode, 2-Pin DO-201AD 1N5402-E3/54

From Vishay, 1N5400-1N5408 are a range of general purpose rectifiers. With a moulded epoxy body, this range of rectifiers have a DO-201AD package size.

• Capable of managing high forward surges.
• Low forward voltage drop.
• Low leakage current.
• Solder dip at +245 °C for a maximum of 10 seconds.
• Flame retardant to UL94 V-O.
• > 500 ns standard recovery.
• Wide operating temperature range of -50 °C to +150 °C.
• Matte tin plated leads, solderable per J-STD-002 and JESD 22-B102.
• A coloured band indicates the cathode end.

1N5400-1N5408 rectifiers are ideal for general purpose rectification in converters, inverters, freewheeling diodes and power supplies.

The Vishay high performance Schottky rectifier diode exhibit very low forward voltage drop with a very fast switching action. It use in low voltage high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.

Operating junction and storage temperature range -65 to +125°C
Very small conduction losses

Diodes and Rectifiers, Vishay Semiconductor
