- RS Stock No.:
- 153-0698
- Mfr. Part No.:
- PMEG6020AELPX
- Brand:
- Nexperia
9000 In stock - FREE next working day delivery available
Added
Price Each (On a Reel of 3000)
£0.109
(exc. VAT)
£0.131
(inc. VAT)
Units | Per unit | Per Reel* |
3000 + | £0.109 | £327.00 |
*price indicative |
- RS Stock No.:
- 153-0698
- Mfr. Part No.:
- PMEG6020AELPX
- Brand:
- Nexperia
Technical Reference
Legislation and Compliance
Product Details
60 V, 2 A low leakage current Schottky barrier rectifier, Planar Maximum Efficiency General Application (MEGA) Schottky barrier rectifier with an integrated guard ring for stress protection, encapsulated in a SOD128 small and flat lead Surface-Mounted Device (SMD) plastic package.
Extremely low leakage current IR = 235 nA
Average forward current: IF(AV) ≤ 2 A
Reverse voltage: VR ≤ 60 V
Low forward voltage VF = 600 mV
High power capability due to clip-bonding technology
High temperature Tj ≤ 175 °C
Small and flat lead SMD plastic package
AEC-Q101 qualified
Low voltage rectification
High efficiency DC-to-DC conversion
Switch mode power supply
Reverse polarity protection
Low power consumption applications
Average forward current: IF(AV) ≤ 2 A
Reverse voltage: VR ≤ 60 V
Low forward voltage VF = 600 mV
High power capability due to clip-bonding technology
High temperature Tj ≤ 175 °C
Small and flat lead SMD plastic package
AEC-Q101 qualified
Low voltage rectification
High efficiency DC-to-DC conversion
Switch mode power supply
Reverse polarity protection
Low power consumption applications
Specifications
Attribute | Value |
---|---|
Mounting Type | Surface Mount |
Package Type | SOD-128 |
Maximum Continuous Forward Current | 2.83A |
Peak Reverse Repetitive Voltage | 60V |
Diode Configuration | Single |
Rectifier Type | Schottky Rectifier |
Diode Type | Schottky |
Pin Count | 2 |
Number of Elements per Chip | 1 |
Diode Technology | Schottky |
Peak Reverse Recovery Time | 9ns |
Peak Non-Repetitive Forward Surge Current | 50A |
