Siemens 3SE5 Series Safety Enabling Switch, 5 Position, 1 NO/1 NC, IP65
- RS Stock No.:
- 153-111
- Mfr. Part No.:
- 3SE5232-3RV40
- Brand:
- Siemens
Subtotal (1 unit)*
£61.47
(exc. VAT)
£73.76
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 22 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £61.47 |
*price indicative
- RS Stock No.:
- 153-111
- Mfr. Part No.:
- 3SE5232-3RV40
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Series | 3SE5 | |
| Product Type | Safety Enabling Switch | |
| Contact Configuration | 1 NO/1 NC | |
| Number of Positions | 5 | |
| IP Rating | IP65 | |
| Terminal Type | Screw | |
| Switch Contact Current | 10A | |
| Housing Material | Plastic | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 60°C | |
| Contact Voltage | 230V ac | |
| Standards/Approvals | UKCA, cULus EAC, IEC 60068-2-27, CE, CCC, EN 50047 | |
| Hazardous Area Certification | NO | |
| Length | 104mm | |
| Mechanical Life | 1000000Operations | |
| Width | 31mm | |
| Select all | ||
|---|---|---|
Brand Siemens | ||
Series 3SE5 | ||
Product Type Safety Enabling Switch | ||
Contact Configuration 1 NO/1 NC | ||
Number of Positions 5 | ||
IP Rating IP65 | ||
Terminal Type Screw | ||
Switch Contact Current 10A | ||
Housing Material Plastic | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 60°C | ||
Contact Voltage 230V ac | ||
Standards/Approvals UKCA, cULus EAC, IEC 60068-2-27, CE, CCC, EN 50047 | ||
Hazardous Area Certification NO | ||
Length 104mm | ||
Mechanical Life 1000000Operations | ||
Width 31mm | ||
The Siemens Safety Position Switch offers a robust plastic enclosure and an array of advanced features to ensure maximum operational safety in various applications. Designed for reliable performance, it boasts slow action contacts and multiple directions of approach, making it versatile in its use. With an impressive mechanical service life of up to one million cycles, this device enhances productivity while minimizing downtime. Its compact design allows for easy installation, and the protection class rating of IP65 ensures it is dust tight and resistant to water ingress. Combining high endurance with top tier safety standards, this switch is an excellent choice for those seeking reliability in demanding environments.
Incorporates positive opening technology for enhanced safety mechanisms
Provides excellent insulation voltage ratings for added reliability
Maintains operational integrity over a wide temperature range from 25 to +85 °C
Complies with international standards for safety and operational excellence
