Siemens 3SE5 Series Safety Enabling Switch, 5 Position, 1 NO/1 NC, IP65
- RS Stock No.:
- 153-109
- Mfr. Part No.:
- 3SE5234-1RV40-1AF3
- Brand:
- Siemens
Subtotal (1 unit)*
£81.78
(exc. VAT)
£98.14
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 25 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £81.78 |
*price indicative
- RS Stock No.:
- 153-109
- Mfr. Part No.:
- 3SE5234-1RV40-1AF3
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Product Type | Safety Enabling Switch | |
| Series | 3SE5 | |
| Contact Configuration | 1 NO/1 NC | |
| Number of Positions | 5 | |
| IP Rating | IP65 | |
| Minimum Operating Temperature | -25°C | |
| Housing Material | Plastic | |
| Contact Voltage | 125V | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | CCC, UKCA, EAC, cULus, CE, TUV | |
| Hazardous Area Certification | NO | |
| Depth | 33mm | |
| Mechanical Life | 1000000Cycles | |
| Width | 31mm | |
| Length | 104mm | |
| Select all | ||
|---|---|---|
Brand Siemens | ||
Product Type Safety Enabling Switch | ||
Series 3SE5 | ||
Contact Configuration 1 NO/1 NC | ||
Number of Positions 5 | ||
IP Rating IP65 | ||
Minimum Operating Temperature -25°C | ||
Housing Material Plastic | ||
Contact Voltage 125V | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals CCC, UKCA, EAC, cULus, CE, TUV | ||
Hazardous Area Certification NO | ||
Depth 33mm | ||
Mechanical Life 1000000Cycles | ||
Width 31mm | ||
Length 104mm | ||
The Siemens Safety Position Switch with separate actuator sets a new standard in operational reliability and safety. Designed to meet rigorous industrial requirements, this product features a robust plastic enclosure that complies with EN 50047 standards. With its mechanical mechanisms, it ensures positive opening, delivering enhanced safety in various applications. The switch is versatile, offering multiple directions of approach while connecting seamlessly to compact block I/O modules. Furthermore, its longevity is demonstrated through an impressive mechanical service life of up to one million operating cycles, making it an ideal choice for demanding environments.
Designed for high operational safety with positive opening function
Environmental adaptability with operational temperature range from 25°C to +85°C
Constructed with a durable plastic enclosure suitable for harsh conditions
Shock resistance capabilities according to IEC standards
Meets stringent protection class IP65 against dust and water
