SKF 29415 E Tapered 75 mm I.D Roller Bearing, 160 mm O.D
- RS Stock No.:
- 209-4135
- Mfr. Part No.:
- 29415 E
- Brand:
- SKF
Subtotal (1 unit)*
£955.09
(exc. VAT)
£1,146.11
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £955.09 |
*price indicative
- RS Stock No.:
- 209-4135
- Mfr. Part No.:
- 29415 E
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Roller Bearing | |
| Inside Diameter | 75 mm | |
| Race Width | 33.5mm | |
| Bore Type | Tapered | |
| Limiting Speed | 4000rpm | |
| Dynamic Load Rating | 600kN | |
| End Type | Closed | |
| Standards/Approvals | No | |
| Series | 29415 E | |
| Static Load Rating | 1430kN | |
| Number of Rows | 1 | |
| Outside Diameter | 160 mm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Roller Bearing | ||
Inside Diameter 75 mm | ||
Race Width 33.5mm | ||
Bore Type Tapered | ||
Limiting Speed 4000rpm | ||
Dynamic Load Rating 600kN | ||
End Type Closed | ||
Standards/Approvals No | ||
Series 29415 E | ||
Static Load Rating 1430kN | ||
Number of Rows 1 | ||
Outside Diameter 160 mm | ||
- COO (Country of Origin):
- SE
The SKF Spherical roller bearings have two rows of symmetrical rollers, a common sphered outer ring raceway and two inner ring raceways inclined at an angle to the bearing axis . The centre point of the sphere in the outer ring raceway is at the bearing axis. Dealing with very heavy radial and axial loads in applications prone to misalignment or shaft deflections can be a real challenge. Meet the challenge with SKF spherical roller bearings. Their high load carrying capacity and ability to accommodate misalignment helps you obtain low maintenance costs and long bearing service life. It offer a wide range of robust spherical roller bearings in both open and sealed variants. Here are examples of applications in which spherical roller bearings might be used:
Renewable energy, Mining, mineral processing and cement, Material handling, Pulp & Paper, Industrial transmission, Metals, and Marine.
High load carrying capacity
Accommodate misalignment
Separable design.
High speed capability
Low friction
