FAG 32303-A 17mm I.D Taper Roller Bearing, 47mm O.D
- RS Stock No.:
- 190-8380
- Mfr. Part No.:
- 32303-A
- Brand:
- FAG
Bulk discount available
Subtotal (1 unit)*
£27.15
(exc. VAT)
£32.58
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £27.15 |
5 - 9 | £26.06 |
10 - 24 | £25.56 |
25 + | £24.99 |
*price indicative
- RS Stock No.:
- 190-8380
- Mfr. Part No.:
- 32303-A
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | FAG | |
Inside Diameter | 17mm | |
Outside Diameter | 47mm | |
Roller Bearing Type | Taper | |
Race Width | 20.25mm | |
Bore Type | Tapered | |
Static Load Rating | 36000N | |
Cage Material | Sheet Steel | |
Number of Rows | 1 | |
Dynamic Load Rating | 36500N | |
End Type | Open | |
Fatigue Limit Load | 3850N | |
Select all | ||
---|---|---|
Brand FAG | ||
Inside Diameter 17mm | ||
Outside Diameter 47mm | ||
Roller Bearing Type Taper | ||
Race Width 20.25mm | ||
Bore Type Tapered | ||
Static Load Rating 36000N | ||
Cage Material Sheet Steel | ||
Number of Rows 1 | ||
Dynamic Load Rating 36500N | ||
End Type Open | ||
Fatigue Limit Load 3850N | ||
High radial loads occur
High axial loads act on one side
Combined loads must be supported (radial and axial forces acting simultaneously)
Precise axial guidance of the shaft is required (locating bearing function)
The bearing arrangement must have very high axial rigidity
The bearing position is operated clearance-free or under preload (single bearings are adjusted against each other)
High running accuracy is required
The load carrying capacity of angular contact ball bearings is no longer sufficient and the higher speed suitability of angular contact ball bearings is not required
The bearings are not required to compensate misalignments
The design objective comprises compact, rigid and economical bearing arrangements with a high load carrying capacity
High axial loads act on one side
Combined loads must be supported (radial and axial forces acting simultaneously)
Precise axial guidance of the shaft is required (locating bearing function)
The bearing arrangement must have very high axial rigidity
The bearing position is operated clearance-free or under preload (single bearings are adjusted against each other)
High running accuracy is required
The load carrying capacity of angular contact ball bearings is no longer sufficient and the higher speed suitability of angular contact ball bearings is not required
The bearings are not required to compensate misalignments
The design objective comprises compact, rigid and economical bearing arrangements with a high load carrying capacity
