NTN 22318EAKW33C3 Tapered 90 mm ID Spherical Roller Bearing, 190 mm OD
- RS Stock No.:
- 640-133
- Mfr. Part No.:
- 22318EAKW33C3
- Brand:
- NTN
Subtotal (1 unit)*
£399.83
(exc. VAT)
£479.80
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 04 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £399.83 |
*price indicative
- RS Stock No.:
- 640-133
- Mfr. Part No.:
- 22318EAKW33C3
- Brand:
- NTN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | NTN | |
| Product Type | Spherical Roller Bearing | |
| Inside Diameter | 90 mm | |
| Race Width | 64mm | |
| Bore Type | Tapered | |
| Cage Material | Steel | |
| Series | 223 | |
| Internal Clearance | C3 | |
| Bearing Material | Through Hardened Steel | |
| Outside Diameter | 190 mm | |
| Number of Rows | 2 | |
| Dynamic Load Rating | 668kN | |
| End Type | Open | |
| Standards/Approvals | No | |
| Maximum Speed - Oil | 3000rpm | |
| Maximum Speed - Grease | 2500rpm | |
| Static Load Rating | 652kN | |
| Limiting Speed | 3500rpm | |
| Select all | ||
|---|---|---|
Brand NTN | ||
Product Type Spherical Roller Bearing | ||
Inside Diameter 90 mm | ||
Race Width 64mm | ||
Bore Type Tapered | ||
Cage Material Steel | ||
Series 223 | ||
Internal Clearance C3 | ||
Bearing Material Through Hardened Steel | ||
Outside Diameter 190 mm | ||
Number of Rows 2 | ||
Dynamic Load Rating 668kN | ||
End Type Open | ||
Standards/Approvals No | ||
Maximum Speed - Oil 3000rpm | ||
Maximum Speed - Grease 2500rpm | ||
Static Load Rating 652kN | ||
Limiting Speed 3500rpm | ||
Non Compliant
- COO (Country of Origin):
- IT
The NTN Spherical Roller Bearing is designed to withstand substantial loads and misalignments, making it ideal for demanding operating conditions. This type of bearing excels in environments such as crushers, vibrating screens, and heavy handling applications. With NTN's ULTAGE design, it delivers exceptional durability and extended service life as a standard feature, offering unparalleled endurance and reliability in harsh conditions.
High impacts resistance
High vibrations resistance
