SKF RNA 4910 58 mm ID Roller Bearing Cylindrical Roller, 72 mm OD
- RS Stock No.:
- 464-774
- Mfr. Part No.:
- RNA 4910
- Brand:
- SKF
Subtotal (1 unit)*
£58.06
(exc. VAT)
£69.67
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Stock information currently inaccessible - Please check back later
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £58.06 |
*price indicative
- RS Stock No.:
- 464-774
- Mfr. Part No.:
- RNA 4910
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Roller Bearing | |
| Inside Diameter | 58mm | |
| Race Width | 22mm | |
| Cage Material | Sheet Steel | |
| Number of Rows | 1 | |
| Bearing Material | Steel | |
| Outside Diameter | 72mm | |
| Dynamic Load Rating | 55kN | |
| Standards/Approvals | RoHS | |
| Series | RNA 4910 | |
| Static Load Rating | 85kN | |
| Limiting Speed | 8000rpm | |
| Bearing Type | Cylindrical Roller | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Roller Bearing | ||
Inside Diameter 58mm | ||
Race Width 22mm | ||
Cage Material Sheet Steel | ||
Number of Rows 1 | ||
Bearing Material Steel | ||
Outside Diameter 72mm | ||
Dynamic Load Rating 55kN | ||
Standards/Approvals RoHS | ||
Series RNA 4910 | ||
Static Load Rating 85kN | ||
Limiting Speed 8000rpm | ||
Bearing Type Cylindrical Roller | ||
The SKF Single row needle roller bearings without an inner ring consist of an outer ring with a needle roller and cage assembly. They are an excellent choice for compact bearing arrangements in applications where hardened and ground raceways can be provided on the shaft. The outer ring includes two integral flanges to guide the bearing axially and an annular groove with one or more lubrication holes to facilitate relubrication.
High radial load carrying capacity
High stiffness
Low cross-sectional height
Accommodate axial displacement in both directions
