SKF 22324 CCJA/W33VA405 Cylindrical 120 mm ID Spherical Roller Bearing, 260 mm OD
- RS Stock No.:
- 462-532
- Mfr. Part No.:
- 22324 CCJA/W33VA405
- Brand:
- SKF
Subtotal (1 unit)*
£1,578.71
(exc. VAT)
£1,894.45
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 04 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,578.71 |
*price indicative
- RS Stock No.:
- 462-532
- Mfr. Part No.:
- 22324 CCJA/W33VA405
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Spherical Roller Bearing | |
| Inside Diameter | 120 mm | |
| Race Width | 86mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Outside Diameter | 260 mm | |
| Internal Clearance | CN | |
| Series | 22324 CCJA/W33VA405 | |
| Static Load Rating | 1120kN | |
| Number of Rows | 2 | |
| Dynamic Load Rating | 1019kN | |
| Standards/Approvals | RoHS | |
| Limiting Speed | 2600rpm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Spherical Roller Bearing | ||
Inside Diameter 120 mm | ||
Race Width 86mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Outside Diameter 260 mm | ||
Internal Clearance CN | ||
Series 22324 CCJA/W33VA405 | ||
Static Load Rating 1120kN | ||
Number of Rows 2 | ||
Dynamic Load Rating 1019kN | ||
Standards/Approvals RoHS | ||
Limiting Speed 2600rpm | ||
- COO (Country of Origin):
- SE
Rupali
The SKF Spherical roller bearings can accommodate heavy loads in both directions. They are self aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. This bearing design offers excellent performance in many types of vibrating machinery. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.
Accommodate misalignment
High load carrying capacity
Accommodate very high vibration levels
Low friction and long service life
Increased wear resistance
