SKF 32014 X/DF Taper Roller 70 mm ID Tapered Roller Bearing, 110 mm OD
- RS Stock No.:
- 461-954
- Mfr. Part No.:
- 32014 X/DF
- Brand:
- SKF
Subtotal (1 unit)*
£247.28
(exc. VAT)
£296.74
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 02 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £247.28 |
*price indicative
- RS Stock No.:
- 461-954
- Mfr. Part No.:
- 32014 X/DF
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Tapered Roller Bearing | |
| Inside Diameter | 70mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Limiting Speed | 5600rpm | |
| Outside Diameter | 110mm | |
| Bearing Dynamic Load Rating | 214kN | |
| Cone Width | 50mm | |
| Standards/Approvals | eClass, RoHS, UNSPSC | |
| Static Load Rating | 305kN | |
| Number of Rows | 2 | |
| Cup Width | 50mm | |
| Race Type | Cylindrical | |
| Bearing Type | Taper Roller | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Tapered Roller Bearing | ||
Inside Diameter 70mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Limiting Speed 5600rpm | ||
Outside Diameter 110mm | ||
Bearing Dynamic Load Rating 214kN | ||
Cone Width 50mm | ||
Standards/Approvals eClass, RoHS, UNSPSC | ||
Static Load Rating 305kN | ||
Number of Rows 2 | ||
Cup Width 50mm | ||
Race Type Cylindrical | ||
Bearing Type Taper Roller | ||
- COO (Country of Origin):
- BR
Omkar
The SKF Matched tapered roller bearings arranged face-to-face (X-arrangement, load lines diverge towards the bearing axis) accommodate high radial loads and axial loads in both directions. The precision manufactured intermediate ring between the outer rings enables a defined internal clearance or preload to be achieved when mounted. Matched tapered roller bearings are typically used in gearboxes, hoisting equipment, rolling mills, and machines in the mining industry.
High radial load carrying capacity
Designed for axial loads in both directions
Relatively high stiffness
Surface finish on the contact surfaces of the rollers and raceways that enhances operational reliability
