SKF 32014 X/DF Taper Roller 70 mm I.D Taper Roller Bearing, 110 mm O.D
- RS Stock No.:
- 461-954
- Mfr. Part No.:
- 32014 X/DF
- Brand:
- SKF
Subtotal (1 unit)*
£228.41
(exc. VAT)
£274.09
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £228.41 |
*price indicative
- RS Stock No.:
- 461-954
- Mfr. Part No.:
- 32014 X/DF
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Taper Roller Bearing | |
| Inside Diameter | 70 mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Outside Diameter | 110 mm | |
| Bearing Dynamic Load Rating | 214 KN | |
| Standards/Approvals | eClass, RoHS, UNSPSC | |
| Number of Rows | 2 | |
| Limiting Speed | 5600rpm | |
| Cone Width | 50mm | |
| Static Load Rating | 305kN | |
| Cup Width | 50mm | |
| Bearing Type | Taper Roller | |
| Race Type | Cylindrical | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Taper Roller Bearing | ||
Inside Diameter 70 mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Outside Diameter 110 mm | ||
Bearing Dynamic Load Rating 214 KN | ||
Standards/Approvals eClass, RoHS, UNSPSC | ||
Number of Rows 2 | ||
Limiting Speed 5600rpm | ||
Cone Width 50mm | ||
Static Load Rating 305kN | ||
Cup Width 50mm | ||
Bearing Type Taper Roller | ||
Race Type Cylindrical | ||
- COO (Country of Origin):
- BR
Omkar
The SKF Matched tapered roller bearings arranged face-to-face (X-arrangement, load lines diverge towards the bearing axis) accommodate high radial loads and axial loads in both directions. The precision manufactured intermediate ring between the outer rings enables a defined internal clearance or preload to be achieved when mounted. Matched tapered roller bearings are typically used in gearboxes, hoisting equipment, rolling mills, and machines in the mining industry.
High radial load carrying capacity
Designed for axial loads in both directions
Relatively high stiffness
Surface finish on the contact surfaces of the rollers and raceways that enhances operational reliability
